Summary of Contents for feelSpace naviBelt
- Page 1 User Manual naviBelt feelSpace GmbH Principal office: info@feelSpace.de Albert-Einstein-Str. 1 www.feelspace.de D-49076 Osnabrück...
-
Page 3: Table Of Contents
The feelSpace naviBelt is a device for recreational and outdoor use with which you can learn and experience a new sense of space. It is worn around the abdomen and indicates, with vibration, in which direction north or a defined destination is located. -
Page 4: About This Manual
The illustrations shown here can differ from the appearance of the actual product. feelSpace GmbH is not liable for loss of functionality or incompatibilities due to modification of the device's software. Safety information and warnings This product contains an in-built battery pack (Lithium ion). Batteries may cause fire or chemical burns if not handled properly. -
Page 5: Delivery Content
The green mark on the inside of the belt should be placed at the level of your navel. Recommendation: Do not wear the naviBelt directly on bare skin, but over a light layer of fabric (e.g. a t-shirt). -
Page 6: Functions
(see section "Use with the feelSpace app", page 6). Functions You can use the 4 buttons on the pocket of the naviBelt to call up various functions. The buttons can be felt and pressed through the fabric Function... - Page 7 Briefly pressing the Favorite button starts or ends navigation to a saved location. This function can only be used if a Bluetooth connection to the smartphone exists and a favorite has been determined via the feelSpace app. Otherwise, there is a short special tactile warning signal (page 11). Compass Briefly pressing the compass button starts or ends the compass mode.
-
Page 8: Use With The Feelspace App
Requirements for your smartphone To use the feelSpace app for Android, you need a smartphone with Android operating system version 4.0.3 or higher. To use the feelSpace app for iOS, you need an iPhone with an iOS version 9.3 or higher. - Page 9 Explanation of the app The graphical representation of the app varies depending on the operating system. inital screen settings beeline navigation for IPhone inital screen menu beeline navigation for Android...
- Page 10 Connect your smartphone to the Internet, activate GPS tracking and activate Bluetooth via the system settings. Open the feelSpace app on your smartphone. The appearance of the app screens varies depending on the operating system. Connect belt o click on "connect belt" in the settings (iPhone). Click on "Connect Belt" in the menu (Android).
- Page 11 The localization track indicates where you've been walking. In the settings you can also adjust the intensity of the vibration, check the level of charge of the naviBelt, see the current app version and the naviBelt firmware version. In the section information you can learn more about the app and how to use it.
-
Page 12: Calibration
Make sure to store the naviBelt when charging it in such a way that no heat accumulation is generated around the control element. Battery life varies depending on the type of use. A new naviBelt can be operated in navigation mode with the app for about 15 hours. -
Page 13: Description Of The Tactile Signals
Description of the tactile signals It vibrates continuously left and right for a short time, then each vibration unit is activated clockwise one after the other. The signal travels twice around the body. Not connected to a smartphone: Recurring simple short vibration pulse which is simultaneously felt on the sides. -
Page 14: Care Instructions
Care instructions Your naviBelt is a high-tech device and should be handled with care. Follow the care instructions to ensure maximum service life. Cleaning: Textile outer cover is washable: Wash the outer cover of the belt occasionally if you use the naviBelt frequently. -
Page 15: Troubleshooting
A deep discharge strains the battery and can thus reduce its service life. If the textile of the naviBelt is wet after use (e.g. by sweat), please separate the outer cover from the technical tube so that the textiles can dry well and be ventilated. - Page 16 Problem: The button on the screen of the app is missing to zoom the map Troubleshooting: to my location. Enable Site Services in your phone's system settings. "("Access to my location") Cause: The location services are not activated. Problem: I can't start the navigation with the Favorite button on my belt, I Troubleshooting: get a strange, short feedback...
-
Page 17: Reclamation
If you have a problem that is not listed here, please contact us. Reclamation The feelSpace naviBelt was developed and manufactured with great care. If there is anything to complain about, you should never open and repair it on your own authority.
