- Page 1 FR 85 F 70A F 90A F 140 USER MANUAL IN ORIGINAL Dok: 101481F-GB 2013...
- Page 2 FR 85 / F 70A / F 90A / F140...
-
Page 3: Table Of Contents
FR 85 / F 70A / F 90A / F140 SWEPAC FR 85 is used to pack ballast under foundations, on pavements, in trenches, etc. The rounded base plate makes the machine very suitable for packing around pillars, foundations, wells, etc. In places with poor access, for example in pipe and cable trenches, the machine is easy to use. -
Page 4: Safety Instructions
F 140 When the machine is parked, ensure that it cannot tip • Hand/arm vibrations, m/s over. The machine may not incline more than 20º (FR 85, Non-vibrated handle 18º). The operator must use ear protectors when working with •... -
Page 5: Signs
FR 85 / F 70A / F 90A / F140 SIGNS Warning Signs Machine Signs MACHINERY Before use, carefully read the manual and its safety instruc- tions so that you can handle the machine safely. Ensure that the manual is always accessible. -
Page 6: Technical Data
FR 85 / F 70A / F 90A / F140 TECHNICAL DATA FR 85 F 90A Net weight .........88 kg Net weight .........108 kg Base plate, l x w ......430 x 430 mm Base plate, l x w ......610 x 560 mm Speed .........approximately 25 m/min... -
Page 7: Technical Description
FR 85 / F 70A / F 90A / F140 TECHNICAL DESCRIPTION FR 85 Control handle Petrol engine Rubber damper Vibration element Base plate Engine plate V-belt Centrifugal clutch Protection silencer Lifting eye F 70A / F 90A Devibrated handle... -
Page 8: Daily Checks
V-belt Drive level surface. Check the tension and condition of the V-belt regularly. Re- place a damaged V-belt with the new type A 30 for FR 85 / F 70A / F 90A, B 30 for F 140. Water Sprinkling System Use only clean water. -
Page 9: Starting
FR 85 / F 70A / F 90A / F140 Oil level Engine power switch Idle Full RPM open Closed Fuel cock Choke Throttle lever BEFORE STARTING AFTER STARTING See Daily Checks on page 8. Switch the throttle lever to idle. -
Page 10: Operating Instructions
FR 85 / F 70A / F 90A / F140 OPERATING INSTRUCTIONS TRANSPORTATION The machine’s vibration elements start when the throttle is The machine has a lifting eye that can be used for a hook or increased. The best packing is achieved at full engine RPM. -
Page 11: Ec-Declaration Of Conformity
FR 85 / F 70A / F 90A / F140 EC-declaration of conformity Manufacturer Swepac AB Blockvägen 3 34132 Ljungby 1. Category: Vibratory plate 2. Type: F70A FR85 F90A F140 3. Engine power: F70A 2,6 kW FR85 3,6 kW F90A 2,6 kW... - Page 12 SWEPAC AB Address Blockvägen 3, 341 32 Ljungby, Sweden, tel. +46 (0)372-156 00, fax +46 (0)372-837 41, E-mail mail@swepac.se, Internet www.swepac.se...
