MAHLE TechPRO VCI1000 Quick Start Manual

TechPRO Diagnostic Scan Tool
®
Quick Start Guide
Thank you for joining the group of MAHLE Service Solutions' TechPRO scan tool users. We look forward
to receiving your input and using it to improve our products.
The TechPRO scan tool is the latest technology for the professional tecnician, a versatile windows-based tool that will help
you analyze, diagnose, and repair today's vehicles. Getting started is as easy as ABCDE.
A

UNPACK

Quick Start Guide
n
VCI (Vehicle Communication Interface)
n
USB Cable*
n
USB Micro Cable Adapter
n
VCI Storage Holster
n
VCI Docking Station
(if purchased with a tablet)
n
* USB cable is used for VCI activation. USB cable is no longer needed unless
your computer is not Bluetooth enabled.
C

CONNECT VCI

1.
Open the TechPRO application
if it isn't already open.
2.
Determine connection type you
wish to use (USB or Bluetooth)
3.
If Bluetooth connection is desired, ensure
that your computer's Bluetooth radio is
turned on and make that selection. If USB
only was selected then connect the VCI to
computer via USB cable.
4.
Plug the VCI into the vehicle's diagnostic
port with ignition in the on position.
5.
Click Continue.
6.
Follow the prompts and Bluetooth
discovery will begin. Your VCI will be
shown in the list after a short search
(note serial number). Select your VCI
and it will be paired to your computer.
(Ignore Windows Bluetooth pairing
prompt if it appears. The VCI will be paired
automatically).
7.
Disconnect VCI from vehicle.
Congratulations!
B

INSTALL SOFTWARE

preloaded TechPRO software, connect to the internet and proceed to step 3 to check for and install updates.)
1.
Connect to the internet (preferably without a proxy server or firewall) and open the
following address in your internet browser: https://www.mahletechpro.com/
2.
Download and run the .exe file. Follow the prompts to install the software.
The Application will start automatically once the install is finished.
3.
Once running, the system will check for and install updates.
D

ACTIVATE VCI

1.
Connect your computer
to the internet.
2.
Open the TechPRO application if it isn't already open.
3.
Connect the VCI via USB cable to the computer.
4.
Wait for Windows to finish the USB device driver
install (this process could take a few minutes).
5.
When the device has been installed you will see
"USB Connection" in the top right.
6.
Click the Activate Subscription button on
the home screen.
7.
At the activation warning screen choose
"Activate Subscription".
8.
Fill in the registration form and submit
(every entry line needs to be completed).
9.
Check your email for the PIN.
10.
Enter PIN and submit.
11.
Wait for PIN acceptance and VCI activation message.
12.
Activation is now complete
attempts you can click "Start Evaluation" and you will have 30 days
to use the tool before you need to activate. Please contact MAHLE
Tech Support if this occurs**
13.
Disconnect VCI from computer.
The TechPRO diagnostic tool is now ready to use
Service Solutions
(If you purchased TechPRO with a tablet with
**after three unsuccessful PIN
6
E DIAGNOSE
1.
Plug the VCI into the
vehicle's diagnostic port.
2.
Bluetooth connect will
be automatic.
3.
If USB connection is
desired, connect USB
cable to computer.
4.
Click Diagnose for OE
Enhanced diagnostics.
5.
Click OBDII for
Generic OBD.
