Pent Bike Shed Instruction Manual
WARNING
UNPACKING SAFELY
Please follow these instructions to unpack your garden building safely
• Two people minimum to unpack
• Place the pallet on firm level ground
• Cut the plastic banding
• Remove each panel by removing screws one column at a time as indicated below
• Check all the components against the instructions / check list

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pent and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Power Pent

Summary of Contents for Power Pent

  • Page 1 Pent Bike Shed Instruction Manual WARNING UNPACKING SAFELY Please follow these instructions to unpack your garden building safely • Two people minimum to unpack • Place the pallet on firm level ground • Cut the plastic banding • Remove each panel by removing screws one column at a time as indicated below...
  • Page 2 (Please note – this image is for illustration purposes only. The shed you ordered may be a different size or roof sloping other way) Power Pent Bike Shed Product Instructions PAGE 2 OF 19...

  • Page 3: Before You Start

    We also strongly advise you to wear safety glasses when installing the felt to protect your eyes. Power Sheds Ltd cannot be held responsible for any damage or injury sustained due to incorrect unloading, unpacking, or assembly of any of our products.
  • Page 4 If you have not chosen to purchase our Power Base then other suitable bases would include a concrete base (75mm of concrete on top of 75mm of hardcore) or a paving slab base (slabs laid on top of 50mm of sharp sand).

  • Page 5: Component Checklist

    Component checklist PAGE 5 OF 19...

  • Page 6: Pre-Assembly

    If you have ordered a Power Base, you will also receive 80mm and 100mm screws. Please note – this is a standard pack used for pent and apex sheds so there may be a number of screws / nails not required.
  • Page 7 70mm screws. This will cover the ends of the floor joists. USEFUL TIP! – If you have purchased a POWER Base you can screw the floor to the timber POWER base below for maximum strength and security.
  • Page 8 2. Your shed will come with a number of wall sections. The quantity of these will depend which size you ordered. Please see the components table to confirm which panels you should have for your Power Pent Bike Shed.
  • Page 9 4. Place the remaining 4ft back wall panel and then the other 2ft / 3ft / 4ft end wall panels and again secure using the 50mm screws provided. Keep going until the back wall and both ends are secured together leaving the front section open. 5.
  • Page 10 8. Once the two panels are on which go at the side both sides of the doors (door wings), you can add the door head. This is the part which has the ‘Power’ brand on. To secure these to the panels below you need to screw up through the door wings and into the door head.
  • Page 11 Make sure all the side walls are square and aligned at the top 9. When you have secured all the wall panels together you then need to secure these to the floor using 70mm screws provided. Screw into the floor with 2x screws for every wall panel (internally) ensuring the screws are driven through the framing at the bottom of the side/gable walls, through the floorboards and into the floor joists.
  • Page 12 Front Top and Gables 1. The Power Pent Shed can be higher at the front or the back – you can choose this as you assemble it. Add the pent front top to the side you want to be higher and screw to the panels below with 50mm screws.
  • Page 13 Roof 1. Your pent will come with two roof panels if it’s 6x4, 6x5 and 6x6 or one roof panel if it is a 6x2 or 6x3. Place the roof panel(s) in place so that the framing on the roof panel rusn parallel with the gables i.e.
  • Page 14 Doors 1. Your shed will come with two doors which you will need to hang. The door with the lock on will go on the right (as you look at the shed from the outside) and the door with the shoot bolts will go on the left.
  • Page 15 Felt Health and Safety – Use safety goggles when installing the roofing felt. 1. Before laying the felt, you will need to attach the low side bargeboards with the 40mm galvanised nails. As you can see there are two for the low side – one at the edge of the roof and one on the underside.

  • Page 16: Finishing Touches

    1. Secure corner strips at each corner of your Power shed with 40mm nails (at least four per strip). Extra strips are provided to cover the joins between side wall panels.
  • Page 17 Power Base Installation Instructions 1. The Power Base will be made up from the pressure treated timbers in the pack (this is the 100mm x 50mm timber). Please consult the diagram in your base fixing pack for the precise layout of your base.
  • Page 18 Take extra care to brush treatment into all wooden components inside and outside. Feel free to change the colour of the building giving you the ‘power’ to style it your own way. Check your base Although your base should be level at the time of assembly, some bases can move over time and if you find this occurs then the building can twist or door may not close properly.
  • Page 19 Returns If Power is not for you and you’d like to return your shed within 14 days of delivery then we will collect the item from you without charging a collection fee. No fuss, no fees! All we ask is that you do not unpack the shed or take the shed off the pallet. You will be able to see the shed panels on the pallet if you want to double check the quality of the shed panels.
