Wulfsberg Electronics COBHAM RMS-555 Pilot's Manual

Radio management system with anti-jamming feature
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REVISION HISTORY
REV DCA
DATE
A
W1176
06/06/2001 -----
B
W17973 05/01/18
NEITHER RECEIPT NOR POSSESSION OF THIS DOCUMENT CONFERS ANY RIGHT TO REPRODUCE, USE OR DISCLOSE, IN WHOLE OR IN PART, ANY
INFORMATION CONTAINED IN THIS DOCUMENT WITHOUT WRITTEN AUTHORIZATION FROM WULFSBERG ELECTRONICS.
TEMPLATE 150-744545-01 REV. E
PRINTED
A
COPY OF THIS DOCUMENT MAY NOT BE THE
LATEST REVISION.
IT IS THE USER'S RESPONSIBILITY TO ENSURE THAT HE OR
SHE IS USING THE LATEST DOCUMENT REVISION.
THE LATEST REVISION MAY BE VIEWED OR PRINTED FROM THE
ELECTRONIC DOCUMENT DISTRIBUTION SYSTEM.
Typed signatures indicate approval. Handwritten signature approval of
this document is on file at Wulfsberg Electronics, Prescott, Arizona.
COBHAM RESTRICTED
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number(ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
DRAWN
CHECKED
-------
Digitally signed by: James Sneed
DN: CN = James Sneed C = US O = Cobham
OU = Cobham Aerospace Communications
Date: 2018.05.10 09:30:47 -06'00'
These commodities, technology or software are
Controlled in accordance with the United States
Export Administration Regulation. When exported
from the United States, diversion contrary to
U.S.Law is prohibited.
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION.
Refer to the DCA and associated markups for a complete description of
the changes incorporated in a revision.
APPROVED
--------
George Story
2018.05.09 14:10:52
-07'00'
Chelton Avionics, Inc.
dba Wulfsberg Electronics Division
Prescott, AZ
DOCUMENT TITLE
PILOTS GUIDE, RMS 555 WITH ANTI-
JAMMING FEATURE
SIZE
LRU
A
RMS555
SCALE: NONE
PUBLISHED
06/06/2001
Digitally signed by David Urban
2018.05.1
Date: 2018.05.10 16:07:33
-07'00'


Published

1 09:02:39
These  commodities,  technology or  software
Are  Controlled in  accordance with the  United
States    Export     Administration    Regulations.
When    exporting    from    the   United  States;
-07'00'
Diversion   contrary   to   U.S. Law is prohibited.
DOCUMENT NUMBER
150-040808
DO NOT SCALE DRAWING
CAGE
CODE
1WZE2
REV
B
