Insignia NS-IMP26SL0 Quick Setup Manual

QUICK SETUP GUIDE
Portable
Ice Maker
NS-IMP26SL0 / NS-IMP26RD2 /
NS-IMP26MT2 / NS-IMP26WH2
Before using your new product, please read these instructions to prevent any damage.

PACKAGE CONTENTS

• Portable ice maker
• Ice basket (pre-installed)
• Ice shovel
• Quick Setup Guide

FEATURES

• Produces up to 26 lbs. (11.8 kg) of ice each day
• Stores up to 1.5 lbs. (.68 kg) of ice
• Quick production cycle creates ice every 6 to 13 minutes
• Auto-detect prevents ice from overflowing when the basket is full
• Two ice cube sizes help create the perfect drink
• Removable ice basket gives you convenient access
• Water recycling system with reservoir lets you place your ice maker
anywhere

IMPORTANT SAFETY INFORMATION

• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not operate your ice maker with a damaged cord.
• Your ice maker requires a standard 110-120volt, 60Hz electrical outlet with a three-prong ground.
• Connect to a properly polarized outlet only. No other appliance should be plugged into the same outlet.
Make sure that the plug is fully inserted into the outlet.
• Do not run the power cord over carpeting or other heat insulators. Do not cover the cord. Keep the cord
away from traffic areas, and do not submerge in water.
• We do not recommend the use of an extension cord because it may overheat and become a risk of fire. If
you must use an extension cord, use No.14 AWG minimum size and rated no less than 1875 watts.
• Unplug your ice maker before cleaning or making any repairs or servicing.
• Exercise caution and use reasonable supervision when your ice maker is used near children.
• Do not use your ice maker outdoors.
• Place your ice-maker away from direct sunlight and make sure that there is at least
4 inches (10 cm) of space between the back and sides of your ice maker and surrounding walls.
• Do not use any other liquid besides water to make ice cubes.
• Do not clean your ice maker with flammable fluids. The fumes can create a fire hazard or explosion.
• Do not tip over.
• If your ice maker is brought in from outside storage in winter, wait a few hours for it to warm up to room
temperature before plugging it in.
• To avoid a hazard due to instability of your ice maker, it must be placed on an even or flat surface.
WARNING: This appliance must be grounded.

OVERVIEW

Control panel
ICE FULL indicator
Ice cube size
Lights when the ice
Lights to indicate the
basket is full. selected ice cube size.
SELECT button
Press to select the
ADD WATER indicator
ice cube size:
Lights when you need
SMALL or LARGE
to add water.
POWER indicator
Lights when your ice
maker is turned on.
ON/OFF button
Press to turn your ice
maker on or off.
Ice maker
Cover
Lift to remove ice.
Ice scoop
Moves ice into the ice basket.
Ice full sensor
Senses when the ice maker is full.
Ice basket
Holds ice.
Ventilation opening
Provides cooling. Do not block.
Water drain plug
Unplug to drain water.
Ice shovel
Use to remove ice from the basket.

UNPACKING YOUR ICE MAKER

Remove the exterior and interior packaging. Make sure that you unpack the
ice basket and ice shovel. If any parts are missing, contact Best Buy customer
service.
Note: Make sure that your ice maker is positioned so that the plug is accessible.
