Next SHOREDITCH 832384 Assembly Instructions

Metal bed

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep ttings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.

PRODUCT INFORMATION

• Made from steel with an antique bronze plated finish and poplar sprung wooden slats.
• Made in China.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use abrasive cleaning products or those containing silicone.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly xings should always be tightened properly and periodically check all fixings and tighten if necessary.
SHOREDITCH METAL BED 832384

ASSEMBLY INSTRUCTIONS.

Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHOREDITCH 832384 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next SHOREDITCH 832384

  • Page 1 SHOREDITCH METAL BED 832384 ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS B. Bolts x4 A. Bolts x12 C. Nut x2 D. Plastic Washer x8 M6X55mm M6X20mm G. Spanner x 1 F. Allen key x1 E. Metal Washer x 18 11mm PARTS (3) Side Rail x 2 (1) Headboard x 1 (2) Footboard x 1 (6) Sprung Slats x 26 (4) Cross Bar x 2...
  • Page 3 STEP ONE 1. Attach side rails 3 (x2) to headboard 1 and footboard 2 using 8 x bolts (A), 8 x plastic washers (D) and 8 x metal washers (E). Tighten using Allen key (F) STEP TWO 1. Attach cross bars 4 (x2) to the brackets on side rails 3 (x2) using 4 x bolts (A) and 4 x metal washers (E).
  • Page 4 STEP THREE 1. Attach centre rail 5 between the brackets on cross bars 4 (x2) using 2 x bolts (B), 4 x metal washers (E) and 2 x nuts (C). Tighten with Allen key (F) and spanner (G). NOTE: Please ensure that the slat cap holes on the centre rail 5 face upwards.
  • Page 5 5. 4. Repeat process for all remaining slats and caps until all components have been used and firmly pushed in place. STEP SEVEN Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 5 of 5...
