- Page 1 Rock-Steady Folding Steel Stand Instructions Effective July 2020 Review full instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent version of instructions for your product.
-
Page 2: General Safety Warnings
Instructions and safety warnings for your product (see operating area; the Instructions link on the product page at Rockler.com). • Do NOT use power tools in explosive environments, or in the presence of flammable liquids, fumes or dust;... - Page 3 PRODUCT SPECIFIC SAFETY WARNINGS > To avoid injury, Safety Locking Pins must be inserted and secured before any weight is placed on the table. > To avoid pinching or crushing your fingers, keep your hands away from the areas > Before using the Rock-Steady Folding Steel Stand, where the legs cross.
-
Page 4: Parts List
Fig. 1 PARTS LIST Quantity Right Leg Assembly Left Leg Assembly Center Angle Brace Rear Leg Stretcher (longest) Middle Leg Stretcher Front Leg Stretcher (shortest) Front Table Bracket (with Safety Locking Pins attached) 1/4"-20 x 2" Machine Screw 1/4" Washer 10 1/4"-20 Nut 11 #8 x 3/4"... - Page 5 Assembly 1. Attach the Center Angle Brace (3) to the back of the long THESE WARNINGS PERTAIN middle legs of the Right and Left Leg Assemblies (1 and 2) with two 1/4"-20 x 2” Machine Screws (8), four 1/4" TO ALL REMAINING STEPS: Washers (9) and two 1/4"-20 Nuts (10) at each mounting location.
- Page 6 Fig. 3 4. Attach the Middle Leg Stretcher (5) to the back of the long register the interior edges of the pivoting rear brackets middle legs of the Right and Left Leg Assemblies (1 and 2) from the Right and Left Leg Assemblies (1 and 2) when with two 1/4"-20 x 2"...
- Page 7 Fig. 4 Inset Tabletop Back Edge ⁄ " ⁄ " ⁄ " Tabletop centerline Hole centered on centerline Tabletop Front Edge Required Bracket Inset Chart Table Depth 20” 21” 22” 23” 24” (Front to Back) Bracket Inset ⁄ ” ⁄ ”...
-
Page 8: Unfolding The Stand
Unfolding the Stand > To avoid pinching or crushing your fingers, keep your hands away from the areas where the legs cross. > Do not sit or stand on table or allow children to climb or play on table. > Ensure table feet are positioned flat; do not use on sloped or uneven ground. - Page 9 1. Position the assembled table and stand upright. 2. Swing out the rear legs until they are stopped by the Center Angle Brace (3) and allow the table and stand to tip backward until the rear feet touch the ground. Make sure that the rear legs are opened as far as they will go and that all four feet are flat.
- Page 10 Center Angle Brace (3). without first inserting and securing the Safety Locking Pins in the Leg Assemblies (1 and 2). Check Rockler.com for updates. If you have further questions, please contact our Technical Support Department at 1-800-260-9663 or support@rockler.com 1.
- Page 11 Fig. 12 Fig. 13 - Left Safety Locking Pin storage location Fig. 14 - Right Safety Locking Pin storage location...
- Page 12 54819 Distributed by Rockler Companies, Inc. 1-800-279-4441 Rev 07/20 4365 Willow Dr. Medina, MN 55340 www.rockler.com...
