POWER GUN
SUCTION ABRASIVE BLAST TOOLS
O. M. 24189
DATE OF ISSUE:
REVISION:
WARNING
Do not use this equipment
before READING this
MANUAL and
UNDERSTANDING its
contents.
These WARNINGS are
included for the health
and safety of the operator
and those in the
immediate vicinity. Failure
to read and understand
these warnings can result
in injury or death.
Electronic files include a
Preface containing the
same important
information as in the
orange cover.
02/06
C, 06/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24189 and is the answer not in the manual?

Questions and answers

Related Manuals for Clemco 24189

Summary of Contents for Clemco 24189

  • Page 1 Failure to read and understand these warnings can result © 2018 CLEMCO INDUSTRIES CORP. One Cable Car Dr. in injury or death. Washington, MO 63090 Phone (636) 239-4300 Electronic files include a Fax (800) 726-7559 Email: info@clemcoindustries.com...

  • Page 2: Table Of Contents

    Power Gun Systems ..........9.2 Blast Gun Assembly, dry blast ....... 9.3 System Replacement Parts ........9.4 Blast Gun Assembly, H2O Model ......9.5 Gun and Trigger Assembly ........9.6 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 3: General Description

    As a result, abrasive chamber and blast stream. Water entering the blast © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 4: Compressed Air And Abrasives

    Failure to use appropriate respiratory equipment can result in injury or death.   © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 5: Setup

    Do not allow anyone around the blasting area (Garden hose swivel) who is not appropriately fitted with approved personal protective equipment, per Section 4.2. Figure 5 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 6: Operator Safety Equipment

    To use bagged abrasive, pierce the bag with the contaminants, where the air is safe to breathe. pointed end of the lance. Insert the lance into the © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 7: Dry Blasting

    Some items rotated for clarity. the mixing chamber and material hose, causing Figure 8 blockage from wet abrasive. © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 8: Shutdown

    Open only enough to suppress dust. Trigger Water Valve Shown fully closed Turn knob counterclockwise to increase blast pressure. Figure 9 Some item rotated for clarity. Figure 11 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 9: Air Induction Valve (Stops Abrasive Flow)

    Figure 12 Figure 13. The jet is a slip fit into the mixing chamber; gouges will interfere with the fit. © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 10: Air Jet, H2O Model (Wetblast)

    6.4.1 Separate the air jet from the mixing chamber. Use a 2.5 mm hex key to loosen the three setscrews © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 11: Converting Dry Blast To H2O Wetblast

    Set the hose aside for holding the jet to the mixing chamber. Then while twisting reuse. the jet to loosen it, pull out to remove it from the chamber. © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...
  • Page 12 * Apply breakaway sealant such as Loctite 243 to the male threads when assembling these parts. **Apply Teflon thread sealant or other common thread sealant to the male threads on these parts. Figure 19 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 13: Troubleshooting

    Repair as needed. holes in the lance are open. When using the lance into bagged abrasive make sure the intake holes are not buried in abrasive © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 14: Abrasive Surge

    30-ft. water hose ........29339 Figure 21 Water Jacket Mixing Chamber Water Valve Air-Induction Valve Water Hose Clamp, Material Hose Water Connection (3/4" Garden hose swivel) Figure 20 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 15: Blast Gun Assembly, Dry Blast

    Hose, air, bulk, specify feet required * Field installation of this clamp requires a BAND-IT® 16-ft. and 30-ft. are standard lengths ..24779 tool, number C00169 or equal. Figure 22 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 16: Blast Gun Assembly, H2O Model

    Setscrew, M5 x 6mm, 6 required ....29253 Valve, 1/4" NPT ball (shutoff) ....29254 Hose, material, bulk specify feet required 16-ft. and 30-ft. are standard lengths ..24778 Figure 23 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

  • Page 17: Gun And Trigger Assembly

    Nut, control knob retaining ......90586 Seal, rod ............ 90595 Stem, control knob ........90587 Gun body and trigger assembly ......Not available as separate item Figure 24 © 2018 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 24189, Rev. C 06/18...

Table of Contents
