DYLAN BED FULL/QUEEN/E.KING SIZE
ASSEMBLY INSTRUCTIONS
BOX #1
A. HEADBOARD: 1PC
BOX #3
C. SIDE RAILS: 2 PCS
DYLAN BED
ASSEMBLED
PARTS AND HARDWARE
PACKING CONFIGURATONS
D. SLAT ROLL: 1 SET
BOX #2
B. FOOTBOARD 1 PC.
E. CENTER LEG: 4 PCS
HARDWARE PACKED IN BOX #3
1.ALLEN BOLT
Ø8x50MM: 8PCS
3. FLAT WASHERS
M8xØ19x1.7: 8PCS
5.ALLEN KEY
M4 x 110: 1PC
F. CENTER SLAT SUPPORT: 1 PC
2. SPRING WASHERS
M8xØ12x1.7: 8PCS
4. SCREW Ø4x30
MM: 27 PCS
