CITY II RAKE LOW PROFILE BED
BOX #1
A.
HEADBOARD
1 PC
B.
FOOTBOARD
1 PC
B
CITY II RAKE LOW PROFILE BED ASSEMBLED
STEP 1 :
FIX ONE OF THE SIDERAILS (C) TO THE
HEADBOARD (A) BY SLIDING IN THE HOOK
INSTALLED AT THE END OF THE SIDERAIL
(C) TO THE HEADBOARD (A), AND PUSH THE
SIDERAIL (C) DOWN TO SECURE THE
CONNECTION.
FULL/QUEEN SIZE
ASSEMBLY INSTRUCTIONS
PARTS AND FITTING PACKAGING DETAIL
A
BOX #2
C.
SIDERAILS
D.
BED SLATS
E.
LEG SUPPORT
HARDWARE BOX
C
HARDWARE PACKED IN BOX #2
ROUND HEAD
12
1
SCREW 15MM
PCS
1
3
ALLEN KEY
PC
TOOL REQUIRED :
PHILLIPS HEAD SCREW
DRIVER (NOT PROVIDED)
A
C
C
MFI
2 PCS
3 PCS
3 PCS
C
D
WOOD SCREW
6
2
PCS
Ø8X30MM
ALLEN BOLT
3
4
PCS
40MM
PUSHING
DOWN
MODUS
FURNITURE
INTERNATIONAL
E
A
Advertisement
Table of Contents
Related Manuals for mFi CITY II RAKE LOW PROFILE BED
Summary of Contents for mFi CITY II RAKE LOW PROFILE BED
- Page 1 BED SLATS 3 PCS FOOTBOARD 1 PC LEG SUPPORT 3 PCS HARDWARE BOX HARDWARE PACKED IN BOX #2 CITY II RAKE LOW PROFILE BED ASSEMBLED ROUND HEAD WOOD SCREW SCREW 15MM Ø8X30MM ALLEN BOLT ALLEN KEY 40MM TOOL REQUIRED :...
