BOX #1
A.
HEADBOARD
1 PC
B.
FOOTBOARD
1 PC
URBAN LOFT BED ASSEMBLED
STEP 1 :
FIX ONE OF THE SIDERAILS ( ) TO THE
HEADBOARD ( )
A BY SLIDING IN THE HOOK
INSTALLED AT THE END OF THE SIDERAIL
( ) TO THE HEADBOARD ( ), AND PUSH
C
DOWN THE SIDERAIL ( ) TO SECURE THE
CONNECTION.
UPDATED : SEPTEMBER 27TH, 2010
URBAN LOFT BED
FULL/QUEEN SIZE
ASSEMBLY INSTRUCTIONS
PARTS AND FITTING PACKAGING DETAIL
A
B
C
A
C
BOX #2
C.
SIDERAILS
D.
BED SLATS
E.
LEG SUPPORT
HARDWARE BOX
C
HARDWARE PACKED IN BOX #2
ROUND HEAD
12
1
2
SCREW 15MM
PCS
1
3
4
ALLEN KEY
PC
TOOL REQUIRED :
PHILLIPS HEAD SCREW
DRIVER (NOT PROVIDED)
C
C
MFI
2 PCS
3 PCS
3 PCS
C
D
WOOD SCREW
6
PCS
Ø
8X30MM
ALLEN BOLT
3
40MM
PCS
MAY CONTAIN
EXTRA HARDWARE
A
PUSHING
DOWN
MODUS
FURNITURE
INTERNATIONAL
E
YOUR BOX
A
