Operator's manual for Attachment
Operator's
Operator's
Operator's
Sand and Salt Spreader
Product number:
Please read this manual carefully before using the equipment, and follow all
instructions.
Keep this manual for later reference.
manual for Attachment
manual for Attachment
manual for Attachment
200-series loaders:
300-700-series loaders:
Sand / Salt Spreader 2011 1
A21114
A2947

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A21114 and is the answer not in the manual?

Questions and answers

Related Manuals for AVANT A21114

Summary of Contents for AVANT A21114

  • Page 1 Attachment manual for Attachment manual for Attachment Sand and Salt Spreader Product number: 200-series loaders: A21114 300-700-series loaders: A2947 Please read this manual carefully before using the equipment, and follow all instructions. Keep this manual for later reference.

  • Page 2: Table Of Contents

    Sand / Salt Spreader 2011 1 CONTENTS Foreword..........................3 Designed purpose of use ......................3 Safety instructions for using the spreader ................3 Sand / salt spreader specifications..................4 Assembly of the spreader......................6 ..................6 5.1. Mounting the spreader to the loader ..............

  • Page 3: Foreword

    3(14) 1. Foreword Avant Tecno Oy would like to thank you for your purchase of this AVANT attachment. It has been designed and manufactured on the basis of years of product development and experience. By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure the reliable operation and long service life of the equipment.

  • Page 4: Sand / Salt Spreader Specifications

    4(14) • Ensure that the unattached spreader is properly supported. Unmount the attachment with care. Ensure that the spreader is properly supported during all inspection and maintenance procedures. • Inspections, cleaning and removing of blockages must be done carefully. • Do not remove the safety grille from the spreader.
  • Page 5 A2947 Working width: 1 000 mm 900 mm Volume: 160 l 200 l Weight (empty): 135 kg 170 kg Maximum input of 22 MPa (220 bar), 22,5 MPa (225 bar), hydraulic energy: 40 l/min 60 l/min Suitable AVANT loader: 300-700...

  • Page 6: Assembly Of The Spreader

    These instructions are applicable to mounting the spreader to the boom quick attach plate of AVANT loaders that have standard quick attach locking. If your machine is equipped with a hydraulic locking and/or serial quick attach system, refer to the relevant manuals for additional mounting instructions.

  • Page 7: Connecting And Disconnecting The Hydraulic Fittings

    7(14) Before moving or raising the attachment, ensure that the locking pins are in the lower position and come through the fasteners both sides. Unlocked attachment may fall on the boom or operator and cause injuries. Do not use the automatic locking of the locking pins at a height of over half a metre. If the locking pins do not return to the normal position when the front plate is tilted, do not raise the attachment any more.

  • Page 8: Instructions For Use

    8(14) 6. Instructions for use Work can be started once the sand / salt spreader is mounted according to the instructions and the hydraulic fittings are connected. Check the attachment and the operating environment once more before starting to work. Quick inspection of the sand spreader prior use is part of ensuring safety and the best performance of the equipment.

  • Page 9: Using The Sand / Salt Spreader

    9(14) Ensure that the loader can handle the load intended to be moved. Notice the risk of the loader tipping forward when material is being lifted from a high level. Do not drag the filled attachment from a high level. Fill the sand / salt spreader only when it is firmly attached to the loader.

  • Page 10: Maintenance And Servicing

    If there are signs of leaking, to check the component, hold up a piece of cardboard in the area where a leak is suspected. Finding any of these faults means that the hydraulic hose or component must be replaced. Spare parts are available from your nearest AVANT retailer or service point.

  • Page 11: The Rubber Lip Plate And The Sweeping Plate

    8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows: •...
  • Page 12 SFS-EN ISO 12100, SFS-EN ISO 4413, SFS-EN 13021 Kuvaus: Avant-kuormainten kanssa käytettävä hiekoitin Beskrivning: Sandspridare; arbetsredskap för Avant lastare Description: Sand spreader; attachment for Avant loaders Beschreibung: Sandstreuer; Anbaugerät für Avant Radlader Mallit / Modeller / Models / Modellen: Avant 200-series...
