- Page 1 E97-811-21 ® ® LAN-90 Process Control View (PCV Harmony/MICRO-DCI Protocol Specific Driver (PSD) (Software Release 5.2) Process Control and Automation Solutions from Elsag Bailey Group...
- Page 2 The information contained in this document is subject to change without notice. Elsag Bailey, its affiliates, employees, and agents, and the authors and contributors to this publication specif- ically disclaim all liabilities and warranties, express and implied (including warranties of merchantability and...
- Page 3 Preface This manual provides general information and guidance with respect to: • The Harmony MICRO-DCI Protocol Specific Driver (PSD). • Hardware requirement and cable connections. • PSD start-up requirements. • Device and data addressing during configuration of the interface. I-E97-811-21B...
- Page 4 ® List of Effective Pages Total number of pages in this instruction is 20, consisting of the following: Page No. Change Date Preface Original List of Effective Pages Original iii through v Original 1-1 through 1-3 Original 2-1 through 2-2 Original 3-1 through 3-3 Original...
-
Page 5: Table Of Contents
Table of Contents Page SECTION 1 - INTRODUCTION ....................1-1 OVERVIEW ........................1-1 REQUIREMENTS ......................1-1 Hardware Requirements..................1-1 Software Requirements ..................1-2 GLOSSARY........................1-2 REFERENCES......................1-3 SECTION 2 - INSTALLATION .....................2-1 SETUP DETAILS FOR RS-232-C/485 CONVERTERS ............2-1 PSD ASSOCIATED FILES DIRECTORY ASSIGNMENTS ..........2-2 SECTION 3 - CONFIGURATION ....................3-1 PSD START-UP FILE ....................3-1 PSD DATA TYPE ASSOCIATION WITH HARMONY DATA TYPES ........3-2 Harmony Data Type 0, Unsigned Integer ..............3-3... - Page 6 ® List of Figures Title Page 2-1. MICRO-DCI RS-485 Physical Interconnections ............2-1 C-1. MICRO-DCI Interface Cable Layouts ..............C-1 List of Tables Title Page 2-1. Hardware Requirements ..................2-2 3-1. Harmony/MICRO-DCI Data Types ................. 3-2 4-1. Group Size, Generic versus MICRO-DCI Data Type ..........4-3 A-1.
- Page 7 Trademarks and Registrations Registrations and trademarks in this document include: ® Elsag Bailey Registered trademark of Elsag Bailey Process Automation. ® INFI 90 Registered trademark of Elsag Bailey Process Automation. ® INFI-NET Registered trademark of Elsag Bailey Process Automation. ® Intel Registered trademark of Intel Corporation.
-
Page 8: Section 1 - Introduction
OVERVIEW This document describes the LAN-90 PCV Harmony Protocol Specific Driver (PSD) for data communication with the Bailey-Fischer & Porter MICRO-DCI controllers. This PSD contains all device specific descriptives for address- ing the various MICRO-DCI devices for data communication. The PSD initiates all communication transactions for the inter- face. -
Page 9: Glossary
PSD, was supplied by Inmac Inc. (part number 800052). The Bailey-Fischer & Porter SCADA adapter was used in the development of this PSD. If a SCADA adapter is in use, it need not be replaced. -
Page 10: References
INTRODUCTION single master/multiple slave protocol for which the LAN-90 PCV is installed as the master drop. This acronym refers to device and protocol specific interfaces (Protocol Specific Driver) developed for the LAN-90 PCV Harmony optional software. RTDB The LAN-90 PCV database comprising a set of console tags (Real-Time DataBase) whose values, states and other information are maintained in real-time. -
Page 11: Section 2 - Installation
(-12 VDC) state. Therefore, these converters are used in the RS-422 mode to disable the tri-state mode on the master. The Bailey-Fischer & Porter SCADA adapter was used in the development of this PSD. However, a third party SCADA adapter may be used. -
Page 12: Psd Associated Files Directory Assignments
“.ttl” file in the form: <ESC> TITLE “MICRO-DCI PSD HELP FILE”. For the actual installation of the PSD, see Elsag Bailey docu- ment I-E97-808-19 where the steps are described in SECTION 2 and APPENDIX A. -
Page 13: Section 3 - Configuration
SECTION 3 - CONFIGURATION PSD START-UP FILE The PSD task is started by the Harmony Executive which assigns a task ID and priority and passes a start-up file name. (See the following example format descriptions.) The start-up file is an ASCII text file in which text lines of the following for- mat contain the start-up arguments: p:XXXXXXXXXX i:X b:BBBB d:N s:N a:XXX p: Specifies a port identification name, XXXXXXXXXX ,... -
Page 14: Psd Data Type Association With Harmony Data Types
CONFIGURATION ® w: NNN w: Specifies delay time NNN when the Executive message exchange mode is Not Reply Blocked. When Reply Blocked is specified, the delay time is ignored. The delay (sleep) time is invoked when the Harmony Executive requires no action from the PSD. -
Page 15: Harmony Data Type 0, Unsigned Integer
CONFIGURATION Harmony Data Type 0, Unsigned Integer A Harmony data type 0 (Unsigned Integer) is associated with MICRO-DCI B-Type variables only. B-Type values have a range 0 to 255. The maximum number of B-Type variables that may be assigned to a Harmony data group is 50. Harmony Data Type 4, Float Harmony data type four (Float) is associated with MICRO-DCI C-Type values. -
Page 16: Section 4 - Operation
SECTION 4 - OPERATION OVERVIEW The PSD software works in tandem with the Harmony 90 sys- tem option to provide an interface between LAN-90 PCV and the MICRO-DCI system. The LAN-90 PCV hardware link up to the RS-485 multidrop network of MICRO-DCI controllers is through an RS-232-C port to an external RS-232-C/RS-485 adapter. -
Page 17: Psd Primary Functions
OPERATION ® PSD PRIMARY FUNCTIONS The primary role of the PSD is to provide protocol specific com- munication for exchanging data between the LAN-90 PCV Har- mony Executive and the MICRO-DCI controllers that are addressable via the specified ports. Only the driver contains external device and communication protocol specific data. -
Page 18: Group Size, Generic Versus Micro-Dci Data Type
OPERATION For example, L800 would indicate to the driver that the group contains digital elements and that the first element of the group is 800 in the controller. A tag could be assigned to any of the elements up to, but not including, the limit of the group size plus the starting address. -
Page 19: Appendix A - Micro-Dci Controller Data Addressing
APPENDIX A - MICRO-DCI CONTROLLER DATA ADDRESSING MICRO-DCI CONTROLLER DATA ADDRESSING Table A-1. Legal MICRO-DCI Controller Data Addressing Controller Data Data File Size Addressing Range Type Type 53MC5000 L-Type 2048 L0000 through L2047 B-Type B000 through B767 C-Type C000 through C767 H-Type H000 through H127 A-Type... -
Page 20: Appendix B - Error Message Table
APPENDIX B - ERROR MESSAGE TABLE ERROR MESSAGE TABLE Table B-1. Error Message Table Number Message Transaction failed to complete - miscellaneous reason. Timeout error on communication. Error reply from host device. Corrupt reply - unrecognizable reply. Communication error with port device. Address error. -
Page 21: Error Message Table
ERROR MESSAGE TABLE ® Table B-1. Error Message Table (continued) Number Message No write access allowed. Group point reference out of range. No device types defined in start-up file. Message too long. Selected port must be primary. Size equal to zero. Group undefined. -
Page 22: Appendix C - Modbus Cable Connections
APPENDIX C - MODBUS CABLE CONNECTIONS MICRO-DCI CABLE CONNECTIONS Figure C-1. MICRO-DCI Interface Cable Layouts NOTE: An Inmac converter must be set to DCE because the PC is DTE and they must be a complementary set. MICRO-DCI CABLE CONNECTIONS I-E97-811-21B C - 1... - Page 23 Visit Elsag Bailey on the World Wide Web at http://www.ebpa.com Our worldwide staff of professionals is ready to meet your needs for process automation. For the location nearest you, please contact the appropriate regional office. AMERICAS ASIA/PACIFIC EUROPE, AFRICA, MIDDLE EAST...
