READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Verse
Installation Guide

Table of Contents:

Wiring. pg. 6
Warranty. pg. 11
4007498
net weight of fan: 18.0 lb. (8.17 kg)
PRINTED IN CHINA
page 1
