OWNER'S MANUAL
ASSEMBLY AND OPERATING INSTRUCTIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE
WARNING
NOTICE TO INSTALLER:
HAZARDOUS EXPLOSION MAY
LEAVE THESE INSTRUCTIONS
RESULT IF THESE WARNINGS AND
WITH THE GRILL OWNER FOR
INSTRUCTIONS ARE IGNORED. READ
FUTURE REFERENCE.
AND FOLLOW ALL WARNINGS AND
INSTRUCTIONS IN THIS MANUAL TO
AVOID PERSONAL INJURY, INCLUDING
DEATH OR PROPERTY DAMAGE.
Advertisement
Table of Contents
Related Manuals for Brinkmann Kettle Grill
Summary of Contents for Brinkmann Kettle Grill
- Page 1 OWNER’S MANUAL ASSEMBLY AND OPERATING INSTRUCTIONS SAVE THIS MANUAL FOR FUTURE REFERENCE WARNING NOTICE TO INSTALLER: HAZARDOUS EXPLOSION MAY LEAVE THESE INSTRUCTIONS RESULT IF THESE WARNINGS AND WITH THE GRILL OWNER FOR INSTRUCTIONS ARE IGNORED. READ FUTURE REFERENCE. AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
-
Page 2: Important Safety
IMPORTANT SAFETY WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL. - Page 3 • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal briquets or lighter fluid in a gas grill. • Leak test all connections before first use, even if grill was purchased fully assembled and after each tank refill.
-
Page 4: Installation Information
• FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as garage, shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors. We recommend your grill be situated at least 10 feet from buildings. - Page 5 The cylinder must also be equipped with: • A shut-off valve terminating in a Type 1 gas cylinder valve outlet. • A Type 1 valve that prevents gas flow until a positive seal is obtained. • An arrangement for vapor withdrawal. •...
-
Page 6: Filling The Lp Gas Cylinder
300°F (115°C and 150°C). If this should happen, remove the entire regulator assembly and throw it away. A replacement regulator assembly can be purchased by contacting Brinkmann at 1-800-527-0717. The cause of the excessive heat should be determined and corrected before using your grill again. - Page 7 • Never use your grill without leak testing all gas connections and hoses. See the section on "Leak Testing" in this manual for proper procedures. The pressure regulator and hose assembly supplied with your gas grill is designed to work with an LP gas supply cylinder.
-
Page 8: Leak Testing
LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •... -
Page 9: Pre-Start Checklist
6. Check each place listed (A -J) for growing bubbles which indicates a leak. 7. Turn OFF gas supply at cylinder valve. 8. Turn on control knob to release gas pressure in hose. 9. Turn control knob to “off” position. 10. -
Page 10: Lighting Instructions
Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections of this manual. LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light the burner so that fumes do not accumulate inside the grill. -
Page 11: Turning Off The Grill
NOTE: Observe flame height when lit: Flame should be a Blue/Yellow color between 1”–2” high. TURNING OFF THE GRILL: 1. Turn OFF the LP tank valve. 2. Turn burner control knob to the OFF position. NOTE: Turn off LP cylinder first to prevent gas from being left in the system under pressure. CAUTION! •... -
Page 12: Controlling Flare-Ups
CONTROLLING FLARE-UPS: • Flare-ups are a part of cooking meats on a gas grill. This adds to the unique flavor of cooking on a gas grill. Excessive flare-ups can over-cook your food and cause a dangerous situation for you or your grill. -
Page 13: Transporting And Storage
Place a protective cap cover on the LP tank and store the tank outdoors in a well ventilated area out of direct sunlight. • If storing the grill outdoors, cover the grill with a grill cover for protection from the weather. A grill cover can be purchased by contacting: The Brinkmann Corporation at 1-800-527-0717. CLEANING AND MAINTENANCE: •... -
Page 14: Cooking Grills
BURNER AND VENTURI • Although your burner is constructed of cast iron, it will rust as a result of the extreme heat and acids from cooking foods. Regularly inspect the burner for cracks, abnormal holes, and other signs of corro- sion damage. -
Page 15: Troubleshooting
TROUBLE SHOOTING: Problem: • Burner will not light • Fire at control knob • Yellow Flames at burner • Flame blows out on "LOW" • Burner does not get hot enough • Grill is Too Hot Possible Causes: 1. Check LP cylinder fuel level. 2. -
Page 16: Proper Care And Maintenance
• To protect your grill from excessive rust, the unit must be kept clean and covered at all times when not in use. A grill cover may be ordered directly from Brinkmann by calling 1-800-468-5252 or 1-800-527-0717. • Wash cooking grill and heat shield with hot, soapy water, rinse well and dry. Lightly coat cooking grill with vegetable oil or vegetable oil spray. -
Page 17: Parts List
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. The following tools are required to assemble this Brinkmann Stainless Steel Gas Kettle Grill: • Pliers •... -
Page 18: Parts Bag Contents
PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. Your Parts Bag will include: PARTS BAG CONTAINS: Hood Nuts Flat washers #8 X 3/8" Sheet metal screws Hood bolts Wing bolts 2 - Hood nuts... - Page 19 Lay cardboard down to protect grill finish and assembly area. Step 1 Place kettle grill body upside down as illustrated. Step 2 Slide all 3 legs with casters into leg supports. Align holes in lower leg with holes in leg supports.
- Page 20 Step 3 Align bottom shelf/tank support with holes in the legs. Step 4 Insert wing bolts through holes in legs into bottom shelf/tank support. NOTE: When securing wing bolts, twist legs for proper alignment with bottom shelf/tank support. Step 5 Secure legs into leg sockets using three #8 X 3/8”...
- Page 21 HIGH Step 6 With the help of a friend, carefully turn the the grill to its upright position. Try to minimize stress placed on the legs. NOTE: Lock casters to prevent grill from moving during final assembly. Step 7 Place dome lid on grill body and align hinges.
- Page 22 Step 9 Place heat shield into lower grill body just above burner. Step 10 Place cooking grill directly above heat shield. Heat shield...
- Page 23 HIGH Ashguard/grease cup holder Step 11 Add control knob to valve by aligning the notched stem of the valve with the cut out on the knob. Step 12 Secure handle to lid using screws and washers provided with handle. Step 13 To install battery unscrew igniter button cap.
- Page 24 Brinkmann Gas Stainless Steel Kettle Grill (Assembled) HIGH LP GAS TANK NOT INCLUDED Your grill is covered with a plastic film to protect the stainless steel finish during shipment and assembly. This plastic film must be removed before operating your grill.
- Page 25 RIB RACK Chrome-plated rack can greatly increase the cooking capacity of your grill. Holds ribs, chicken halves, potatoes and corn vertically to triple cooking capacity. Allows smoke, steam and heat to penetrate food evenly. 600-0062-3 ACCESSORIES PROFESSIONAL SHISH-KABOB SKEWERS These heavy-duty, 18" shish-kabob skewers are extra-long for fabulous restaurant style kabobs.
- Page 26 Restaurant-style aluminum fry pan with nickel plated wire straining basket is an essential tool for frying fish, chicken, french fries, onion rings and more. Strainer basket holder helps drain excess oil. Use outdoors with the Brinkmann Stainless Steel Gas Kettle Grill and avoid the mess and odor of frying indoors.
-
Page 28: One-Year Limited Warranty
Brinkmann Corporation will not be responsible for any grills forwarded to us without prior authorization. Brinkmann Gas Stainless Steel Kettle Grill must be returned to the original place of purchase for replacement of the unit. EXCEPT AS ABOVE STATED, THE BRINKMANN CORPORATION MAKES NO OTHER EXPRESS WARRANTY.
