- Page 1 Modbus Amazon Echo READ AND SAVE THESE INSTRUCTIONS SPA CONTROL INTERFACES Addendum manual for installation and operation for use with Modbus, KNX & Amazon Echo (Alexa) interfaces Humidification and Evaporative Cooling...
- Page 2 Condair Group AG, except to the extent required for installation or maintenance of recipient's equipment. Liability Notice Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due to the use of parts/components/equipment that are not authorised by Condair Group AG. Copyright Notice ©...
-
Page 3: Table Of Contents
Contents Introduction Notes on this addendum manual For your safety Modbus interface Technical data Network structure Modbus RTU Connection and configuration of the Modbus interface Modbus Parameters KNX & Amazon Echo (Alexa) interface Connection of the SPA control board to the KNX gateway Connection of the KNX gateway to a KNX network Connection and configuration of the Modbus interface KNX Addresses... -
Page 4: Introduction
Introduction Notes on this addendum manual Subject of this addendum manual is the operation of the Control Delta SPA Control Box or the Condair Omega via the Modbus or KNX interface. This addendum manual is intended for use by engineers and properly trained technical personnel. Please read this manual thoroughly before installing and configuring the corresponding interfaces. -
Page 5: For Your Safety
Condair Group AG. It is assumed that all persons working on the Modbus or KNX interface of the Condair Delta SPA Control Box or the Condair Omega are familiar and comply with the appropriate regulations on work safety and the prevention of accidents. - Page 6 "Off" position against inadvertent switching on. Preventing unsafe operation If it is suspected that safe operation of the SPA systems is no longer possible, the Condair Delta SPA Control Box or the Condair Omega should immediately be shut down and secured against ac- cidental power-up.
-
Page 7: Modbus Interface
Modbus interface Technical data Protocol Modbus RTU Interface EIA-485 (RS485) (2-wire / GND) Galvanic isolated Connection Plug-in screw terminal 4-pole: 24 VDC / Data + / Data - / GND Telegram format 1 Start bit / 8 data bit / 1 Parity bit / 1-2 Stop bit(s) Data check CRC according to Modbus RTU specification Modbus address... -
Page 8: Network Structure Modbus Rtu
Every Modbus device address can only be allocated once within the same network. The Condair Omega or the Condair Delta SPA Control box always acts as a slave. In the master-slave principle, only the master (e.g., control computer) can initiate data transmission. The affected slave (Condair Omega or Condair Delta SPA Control box) responds to this and delivers the queried data to the master or performs the action requested by the master. -
Page 9: Connection And Configuration Of The Modbus Interface
To connect the Modbus interface, proceed as follows: 1. Switch off the Condair Delta SPA Control Box or the Condair Omega via the unit switch. Set the external electrical isolator(s) in the mains supply/supplies to "Off" and secure the electrical isolator(s) in the off position against unintentional switching on. - Page 10 5. Connect the cable (3 x 0.34mm ) to the RS485 terminal block "X4" on the control board of the Condair Delta SPA Control Box or the Condair Omega. RJ45 CR 2032 Fig. 3: Connecting the interface cable 6. On the last unit in the network jumper "JP2" must be set (terminating resistor at the beginning and end of the network).
- Page 11 7. Set the desired Modbus parameters via the SPA display or the integrated web interface under "En- gineering > SPA Control Board > Modbus Settings > Gateway". Setting via SPA display Gateway Gateway Slave Address Data Format ABCD: big endian Baudrate 19200 Parity...
-
Page 12: Modbus Parameters
Modbus Parameters If a SPA control board is operated in system mode "Wellness Dual", 2 cabins can be controlled (dual cabin application for small cabins). In all other cases, only the parameters for cabin 1 are relevant and all parameters for the cabin 2 can be neglected. Note: For dual cabin application for medium size cabins, two SPA control boards are required, both of them must be connected to the Modbus network. - Page 13 Description Range Input/Holding Format Register 1-based Read with function 03 Write with function 16 Current time of day since mid- 0 – 86400 s 4128 night in seconds, e.g.: 10:00 = 10*3600 Current date in seconds based 0 – x s 4132 on reference date/time (ref- erence date: 01.01.2010).
-
Page 14: Knx & Amazon Echo (Alexa) Interface
KNX & Amazon Echo (Alexa) interface To control the Condair Delta SPA Control Box or the Condair Omega with KNX or Alexa, an optional gateway (LogicMachine5 Lite from embedded systems) is available, which must be mounted outside the corresponding device. - Page 15 All SPA control boards that are to be controlled must be connected to the KNX Gateway via the Modbus interface according to the wiring diagram above. – Connect the cable shield on one side with the functional earth – Connect all GND together –...
-
Page 16: Connection Of The Knx Gateway To A Knx Network
Connection of the KNX gateway to a KNX network 24V in KNX Gateway LM5-L RS485 RS485/RS232 SPA control board 1 SPA control board 2 (Server ID= 0) (Server ID= 1) Fig. 5: Connecting the KNX gateway to a KNX network The KNX Gateway is connected to the KNX network according to the wiring diagram above. -
Page 17: Connection And Configuration Of The Modbus Interface
To connect the gateway, proceed as follows: 1. Switch off the Condair Delta SPA Control Box or the Condair Omega via the unit switch. Set the external electrical isolator(s) in the mains supply/supplies to "Off" and secure the electrical isolator(s) in the off position against unintentional switching on. - Page 18 5. Connect the cable (4 x 0.25mm , SPA control board 1 or 3 x 0.25mm , SPA control board 2) to the RS485 terminal block "X4" on the control board of the Condair Delta SPA Control Box or the Condair Omega. 24 VDC...
- Page 19 7. Set the following Modbus parameters via the SPA display or the integrated web interface under "Engineering > SPA Control Board > Modbus Settings > Gateway": Parameter Value Slave Address Baud rate 19200 Parität Even, 1 stop bit Data Format ABCD: big endian For dual cabin application for medium size cabins, 2 SPA control boards must be connected to the gateway.
- Page 20 Setting via web interface KNX & Amazon Echo (Alexa) interface...
-
Page 21: Knx Addresses
The current data value of each KNX group address can be read with "GroupRead". Partitioning of the group address: Part_1/Part_2/Part_3 Part_1: SPA Control unit 10: Condair Omega steam generator or Condair Delta SPA Control Box Part_2: System range 10/0: Basic system settings 10/1: Cabin 1 10/2: Cabin 2 (only relevant if a system with dual cabin application is used). - Page 22 KNX & Amazon Echo (Alexa) interface...
- Page 23 KNX & Amazon Echo (Alexa) interface...
- Page 24 KNX & Amazon Echo (Alexa) interface...
-
Page 25: Control With Amazon Echo (Alexa)
Control with Amazon Echo (Alexa) In order to control a device with Alexa, a valid Amazon Echo account must be set up. The following link provides step-by-step instructions on how to integrate Alexa voice control into the gateway: http://openrb.com/amazon-echo-alexa-integration/ The following steps show an example of how Alexa speech commands can be defined: 1. - Page 26 2. The KNX Gateway can be addressed via a web browser (Chrome, Firefox, Safari are supported) by typing "HTTP: // IP" in the address bar. Ex factory the following settings are configured: Login name admin Password admin IP address 192.168.0.10 Network mask 255.255.255.0 Note: A secure connection can be established via "HTTPS://IP:Port".
- Page 27 4. Connect KNX Gateway to the Internet. Ethernet cable Internet 24V in KNX Gateway LM5-L RS485 RS485/RS232 SPA control board 1 SPA control board 2 (Server ID= 0) (Server ID= 1) Fig. 9: Connecting the KNX Gateway to the Internet Make sure that all network settings (IP, Gateway, DNS) under "System config >...
- Page 28 7. Go to the App Store by clicking the + icon. 8. Choose "Alexa" and install this app. 9. On the main screen the Amazon App now appears which must be selected. 10. Log in with the LogicMachine Cloud Account, which was set up in step 4. KNX &...
- Page 29 11. Ex factory there are already some examples that make it easier for you to set voice commands. The following commands are available: Action Voice command Start steam bath session "Alexa, turn on steam bath” Stop steam bath session "Alexa, turn off steam bath" Switch on service light "Alexa, turn on service light"...
- Page 30 12. Synchronize with the cloud when you have made modifications. After successful synchronization, the sync button will show the time of the last synchronization: Note: Following each modification on the LogicMachine (adding/removing/editing devices), the fol- lowing steps must be done: –...
- Page 31 13. Log in to "http://alexa.amazon.com" with your Amazon account. Under the heading "Skills", look for LogicMachine. 14. Log in with the LogicMachine Cloud Account (which was set up in step 4). 15. Search for devices in the Alexa account or via the voice command "Alexa, discover devices". KNX &...
- Page 32 Alexa now finds the devices, which are listed under point 11. Further example commands for Alexa voice control can be found under "http://openrb.com/amazon- echo-alexa-integration/". KNX & Amazon Echo (Alexa) interface...
- Page 33 Notes...
- Page 34 Notes...
- Page 36 CONSULTING, SALES AND SERVICE: CH94/0002.00 Condair Group AG Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland Phone +41 55 416 61 11, Fax +41 55 588 00 07 info@condair.com, www.condairgroup.com...
