Please unpack your delivery carefully and inspect the radiator and contents – any
damages or shortages must be notified to your supplier within 3 days of delivery of
your goods.
SPECIFICATIONS FOR VELA ELECTRIC RADIATOR
Power Supply:
Power control type:
Max power:
Insulation class:
Environment protection classification:
Operating temperature:
Storage temperature:
NTC sensor:
Connection type:
Regulation type:
Temperature settings range:
User interface type:
Visualization interface:
Vela Electric Instructions
230V 50Hz +/-10%
RELAY 10A, TRIAC 10A, TRIAC 4A
2000W total (Relay + TRIAC 1 + TRIAC 2)
Class II
IPX4
0 – 50°C
-20 – 85°C
10KOhm @25°C
2
Screw header 2,5mm
(Relay) Hysteresis +/- 0,5°C – (Triac) PID
7– 31°C
Push-button, potentiometer
STN LCD display, viewing angle 12 o'clock, red back-
light
Advertisement
Table of Contents
Related Manuals for DQ Vela Electric
Summary of Contents for DQ Vela Electric
- Page 1 Please unpack your delivery carefully and inspect the radiator and contents – any damages or shortages must be notified to your supplier within 3 days of delivery of your goods. SPECIFICATIONS FOR VELA ELECTRIC RADIATOR Power Supply: 230V 50Hz +/-10%...
- Page 2 INSTALLATION and FIXING Wall Brackets – Offer up the radiator in the desired position, mark the bracket positions and fixing holes. The radiator should be placed a minimum of 10cm from the floor. Using the appropriate drill and fixings attach the brackets to the wall. After installing the plastic inserts into the hook part of the bracket the radiator can then be hung from the brackets Display and symbol description...
- Page 3 THERMOSTAT INSTRUCTION MANUAL Please note: The clock needs to be set before use. Setting Setting the clock can only Standby To turn the unit on or enter be done while the unit is in “stand by” mode Press and the clock Mode “stand by “mode.
- Page 4 TERMS AND CONDITIONS You must immediately remove all packaging, inspect the goods and notify us of any damage to the goods within 3 days of delivery. We shall have no obligation to replace or repair damaged goods in the event of failure by the Buyer to comply with this provision.
