resi-linx digi-MOD RL-DM1102 Quick Install Manual page 2

Hardware Connection
1. Connect the required AV cable (Component
(eg: Cabel TV, Pay TV, DVD. VCR, Camera) to the appropriate connection on the rear of the RL-
DM1102 Modulator
2. Video Input is defaulted for composite video (CVBS). For component and S-Video sources, change
Video Input via "Encoder Setup/Video Input". Once selected press OK to save
3. Connect the RCA cable from the audio source to the red/white Audio Input
of the RL-DM1102 Modulator
I
4. Connect the RF Output from the RL-DM1102 to the Modulator Input on the RF Distribution Module
RL-RF380. Alternatively connect the RF Output to an existing distribution system or directly to a
television set
5. Connect the supplied 12V DC Switch Mode Power Supply to the Power Input
6. Connect IR emitters RL-IR700/800 to the IR output
the other end of the emitter on your AV device near the IR pick up
NOTE: When Remote Power Switch K is ON - the RL-RF380 should not have a Power Supply connected
Initial Startup
1. Power Up the RL-DM1102
2. Enter Password "0000" and press "OK"
3. Wait until digi-MOD reads "Running" then enter the menu by selecting the "OK" button
4. The LCD screen will now display "ADVANCED MENU OUTPUT CHANNEL" - select the "OK" button
5. The LCD screen will now display "OUTPUT CHANNEL 21" with the frequency in MHz. In some TV
sets Channel 21 is not available, so it is recommended to change this to appropriate available output
channel to suit your installation (40, 50, 60 etc.) Once you have scrolled and selected a channel
number, Select "OK" to lock in the change
6. Change any other settings via the "MENU" as required (refer to full installation manual @ resi-linx.
com)
7. Once finished programming use the "UP" scroll button until the LCD display reads "ADVANCED MENU
EXIT", select "OK"
8. The LCD will now read "EXIT, EXIT MENU". Select "OK". The LCD display will now show "Running"
9. Auto Scan for Channels on the TV set with the digi-MOD connected and powered
10. Sources for selected digi-MOD Channel selection, (e.g channel 40), are found on TV channels 101
(adjustable - refer to Programming LCN)
NOTE: If the digi-MOD is powered down, there is no need to reconfigure. All settings will remain
unless a factory default is done.
G H
F , Composition or S-Video ) from the video source
(Audio L & R) on the rear
G
E
L on the rear of the RL-DM1102 Modulator. Place
Programming
CHANNEL NAME can be changed by using the Scroll "UP" key until you reach "CHANNEL NAME". Use
the UP/DOWN scroll keys to change each letter. Click "OK" to confirm channel name change.
LCN (Logic Channel Number) can be moved from its default position (101, 102, 103 and 104) to a different
channel number (e.g. 4, 5, 6, 8) by scrolling UP/DOWN in the LCN option for each channel. Once selected,
press the "OK" button to lock your channel change.
For more programming option, please refer to the full installation manual @ resi-linx.com.
Installing multiple digi-MOD's in an installation
Please ensure each digi-MOD has different settings in the categories below if you are installing 2 or more
in an installation.
OUTPUT CHANNEL
STREAM (TS) ID
CHANNEL NAME
LCN
NOTE: Failure to change the above settings will result in conflict and will not install all channels
correctly.
For web management/programming of the RL-DM1102, please refer to full installation manual
@ resi-linx.com.
Safety Precautions
• Do not apply power to the DVB-T Digital Modulator until all components have been installed and all wiring has been
properly terminated. Failure to do so may result in damage to the product and void manufacturer's warranty.
• Do not attempt to terminate, change or un-install any wiring without first unplugging Power Adapter from the DVB-T
Digital IR Modulator.
• Do not expose any component to moisture. Doing so can create electrical hazards or render the component
unusable. Exposure to moisture will also void the warranty on the system.
• This modulator is powered with a voltage of 12 VDC. The power supply voltage must not exceed this, otherwise this
modulator could suffer irreparable damage and subsequent invalidation of the warranty.
Note:
-
Do not replace the power supply with a voltage greater than 12 VDC.
- Do not connect the modulator to the power if the power cord is damaged.
- Do not plug the modulator into the mains supply until all cables have been connected correctly.
- Do not cut the cord.
• Avoid placing the modulator next to central heating components and in areas of high humidity.
• Do not cover any modulator elements that could obstruct the ventilation slots and cause overheating.
• If the modulator has been kept in cold conditions for a long time, keep it in a warm room no less than 2 hours before
plugging it into the mains.
• Do not place digi-MOD on top or underneath a PVR Device, as this could cause overheating.
