PowerMeter Installation

1. Install the SRM PowerMeter according to the original crank manufacturer's instructions.
2. Depending on the bike frame, you may need to purchase the correct bottom bracket and/
or adapters.
3. It is recommended that you have the SRM PowerMeter installed by an authorized dealer.
To locate an SRM authorized dealer visit our website at:
Cadence Magnet Installation Options
1. The recommended position for the cadence magnet is on the underside of the bottom
bracket.
2. Make sure the magnet is positioned between 21-51 mm from the center point of the
bottom bracket shell. The cadence magnet must be installed properly in order for the
PowerMeter to turn on and measure cadence.
3. Once the magnet is in the correct position the PowerMeter can be turned on by rotating
the cranks, refer to PowerControl or device manual to pair and confirm proper magnet
position.
http://www.srm.de/dealer/
3
PowerMeter Serial Number [PM]
PowerMeter Slope [S]
Installation
