Declaration of Conformity
We, Manufacturer/Importer
OvisLink Corp.
5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien Dist., New Taipei City 231, Taiwan
Declare that the product
48V All-in-One PoE Power Adapter with DC Injector
AirLive POE-48PBv2
is in conformity with
In accordance with 2004/108/EC Directive and 1999/5 EC-R & TTE Directive
Clause
■ EN 55022:2010
■ EN 55024:2010
■ EN 60950-1:2006 + A12:2011
■ CE marking
Manufacturer/Importer
Signature:
Name:Albert Yeh
Position/ Title : Vice President
English
EN
Package Content:
■
48V All-in-One PoE Power Adapter with DC Injector
■
QIG
Hardware:
POE-48PBv2 has two connection ports, one power plug.
1. POE port: It is a RJ-45 Ethernet port for transmitting
power and data to PD, such as PoE AP, PoE Splitter.
2. LAN port: it is a RJ-45 Ethernet port for connecting LAN
port of device, such as Ethernet Switch.
3. Power Plug : it connects power outlet on the wall.
Installation Steps:
1. Connect Power In of POE-48PBv2 to power outlet.
2. Connect LAN of POE-48PBv2 to a Ethernet switch.
3. Connect POE port of POE-48PBv2 to PoE device.
Important Notice:
1. The port which connects POE-48 PBv2 to PD is POE port.
2. The port which connects POE-48 PBv2 to Ethernet switch is LAN port.
Deutsch
DE
Packungsinhalt:
■
48V All-in-One PoE Netzteil mit DC Injektor
■
Schnellstartanleitung
Hardware:
Der POE-48PBv2 besitzt zwei Ports und einen Stromanschluß.
1. POE Port: Dies ist der stromführende RJ-45 Ethernet Port
für den Anschluß eines PoE Gerätes (z.B. AP, Splitter).
2. LAN Port: Dies ist ein RJ-45 Ethernet Port zum Anschluß
an das Netzwerk (z.B. an den Ethernet Switch).
3. Stromanschluß : dieser Anschluß gehört in die
Steckdose.
Installationsschritte:
1. Stecken Sie den POE-48PBv2 in eine Steckdose
2. Verbinden Sie den LAN Port des POE-48PBv2 mit einem
Ethernet Switch.
3. Verbinden Sie den POE Port des POE-48PBv2 mit einem
PoE Gerät.
Important Notice:
1. Der stomführende Anschluß am POE-48 PBv2 ist der POE Port.
2. Der Port, der den POE-48 PBv2 mit dem Netzwerk verbindet, ist der LAN Port.
Description
Limits and methods of measurement of radio disturbance
characteristics of information technology equipment
Information Technology equipment-Immunity characteristics-Limits
and Methods of measurement
Safety for information technology equipment including electrical
business equipment
Place:Taiwan
Date:2012/04/26
Power Plug
POE
LAN
LAN Port
POE Port
Stromanschluß
POE
LAN
LAN Port
POE Port
Česky
CZ
Obsah balení:
■
48V All-in-One PoE Power adaptér s DC injectorem
■
Instalační příručka
Hardware:
POE-48PBv2 má dva přípojné porty a jeden elektrická port.
1. POE port: Je RJ-45 Ethernet port pro přenos dat a elektrické
energie po síťovém kabelu. Např. AP, IP kamera, ... .
2. LAN port: Je RJ-45 Ethernet port pro připojení síťového
zažízení, jako je třeba switch.
3. Power Plug : Pro připojení elektrické energie.
Instalační kroky:
1. Připojte Power In do zásuvky.
2. Připojte LAN do switche.
3. Připojte POE do PoE zařízení.
Důležité:
1. Port pro připojení PoE síťového zařízení s napíjením je POE port.
2. Port pro připojení síťového zařízení (switch, ...) je LAN port.
Español
ES
Contenido del paquete:
■
Adaptador de corriente PoE de 48V con DC todo en uno
■
Guía de instalación rápida
Hardware:
POE-48PBv2 tiene dos puertos de conexión y uno para enchufar.
1. Puerto POE: puerto RJ-45 de Ethernet para transmitir
corriente y datos al PD como PoE AP y PoE Splitter
2. Puerto LAN: puerto RJ-45 para conectar el LAN del
dispositivo como el Ethernet Switch
3. Enchufe de corriente: para conectar corriente en la
pared
Pasos de instalación:
1. Conectar el Power In del POE-48PBv2 a la salida de corriente
2. Conectar el LAN del POE-48PBv2 al switch Ethernet
3. Conectar el puerto POE del POE-48PBv2 al dispositivo PoE
Noticia importante:
1. El puerto que conecta el POE-48PBv2 al PD es el puerto POE
2. El puerto que conecta el POE-48PBv2 al Ethernet switch es el puerto LAN
Power Plug
POE
LAN
LAN Port
POE Port
Enchufe de
corriente
POE
LAN
LAN Port
POE Port
