A-FRAME
Aerial Apparatus
Hoop | Hammock | Silks
INSTRUCTION MANUAL
X-Pole's new Aerial 'A' Frame is perfect for Aerial Fitness, Yoga, Aerial Hoop and Low Silks.
The A- frame can be used from 2235mm (7.6ft) up to 3350 (11ft) with di erent multiple heights being
selectable in-between.
The A-FRAME comes with 2 adapters which can be moved around so you can use the A-FRAME for
multiple disciplines.
The A-FRAME will come in 7 Pieces, 4 x telescopic legs with feet attached, 2 connectors and a 1.4m
Top Bar. Pins, straps and carry bags (1x Frames tubes, 1x Connectors and accessories) are also
supplied. Additional weight bags that can be used with the A-FRAME may be purchased separately.
Adjustable/Multiple Heights using the telescopic legs – allowing you to use indoors or outdoors.
Quick Assembly – all pieces can be stored safely in multi-piece bag.
Multi-discipline – swap between silks, trapeze (static) hammock and hoop!
Portability – Light-weight frame allows the user to take it anywhere with them!
1
Copyright © Vertical Leisure LTD 2014 | All rights reserved.
Version: 1.01
Advertisement
Table of Contents
Related Manuals for X-pole A-Frame
Summary of Contents for X-pole A-Frame
- Page 1 The A-FRAME comes with 2 adapters which can be moved around so you can use the A-FRAME for multiple disciplines. The A-FRAME will come in 7 Pieces, 4 x telescopic legs with feet attached, 2 connectors and a 1.4m Top Bar. Pins, straps and carry bags (1x Frames tubes, 1x Connectors and accessories) are also supplied.
- Page 2 Aerial exercise is extremely physical and uses muscles that you will not have used before and therefore if you are not warmed up; muscle damage, strains and injury can occur. Before using the A-FRAME it is mandatory to warm up and, after use, cool down.
- Page 3 Safety is a priority at all times. If you have ANY questions – before you assemble, install or use your A-FRAME – contact your point of purchase or see the A-FRAME section on the website (www.xpole.com – first select your region, then search for the A-FRAME).
- Page 4 Carry Case REMOVING THE PACKAGING The A-FRAME is packaged in a special way to protect all the parts from any damage during transit. It is very important to remove all the packaging prior to commencing installation. Whilst unpacking the items, please make sure you follow the Contents Diagram.
- Page 5 When the A-FRAME is at its lowest height, it will The A-FRAME could be extended from its lowest require a floor area of sqm2 and when fully height of xxxx mm to a height of xxxx mm when retracted will require an area of sqm2.
- Page 6 ATTACHMENT OF LEGS Insert the leg starting with the hole at the bottom in the triangular bar. Place the leg into the Triangular Insert and line up the holes on the legs with the holes in the Triangular Insert. There will be a ‘guide’ line on the legs to help with this process.
- Page 7 LIFTING THE A-FRAME As the A-FRAME will be assembled on the floor and then lifted into position, it is importamt to allow enough space to do so. Copyright © Vertical Leisure LTD 2014 | All rights reserved. Version: 1.01...
- Page 8 (please ensure that the pins are positioned in the inside of the A-Frame & the legs are pinned back into position using the adjustment line to align). Repeat this process on the right side of your view. Please ensure both sides are level and extended evenly.
