Pro Lite Digi-Brite G3i Wiring Manual

Gas price changer power supply

Advertisement

Quick Links

WARNING
Before beginning installation,
confirm your power supply model.
MODELS SP-150-12 OR SP-320-12
Instructions begin on Page 1
MODELS CLG-100-12
Instructions begin on Page 17

Advertisement

loading

Summary of Contents for Pro Lite Digi-Brite G3i

  • Page 1 WARNING Before beginning installation, confirm your power supply model. MODELS SP-150-12 OR SP-320-12 Instructions begin on Page 1 MODELS CLG-100-12 Instructions begin on Page 17...
  • Page 2: Installer Notice

    INSTALLER NOTICE: Pro-Lite is not responsible for the wiring of the Gas Price sign, installer must reference UL SAM manual for installation requirements. Pro-Lite can only recommend which Class 2 Power Supply to use and cautions you, the installer, which type of wiring is NOT allowed by UL. Please reference UL SAM manual for proper wiring instructions.
  • Page 3 READ ME FIRST – DO’S AND DON’TS ............SP-SECTION 1 –...
  • Page 4 DON’TS  Do not cut into the Gas Pricer PCB at any point.  Do not drill into the Gas Pricer PCB.  Do not cut/modify any part of the Gas Pricer extrusion.  Do not cut/modify any part of the Gas Pricer mounting brackets. ...
  • Page 5: Read Instructions

    READ INSTRUCTIONS  Make sure you read and understand all instructions.  Retain instructions for future reference.  Follow all warnings and instructions indicated in this wiring guide including those marked on the product. BEFORE WIRING  During installation do not allow the AC power to be connected inadvertently. DURING OPERATION ...
  • Page 6 Model: SP-150-12 AC Voltage Input : 110 ~ 120VAC AC Amperage : 2.5A DC Voltage Output : 12VDC UNITS: MM Page 4...
  • Page 7 Model: SP-320-12 AC Voltage Input : 110 ~ 120VAC AC Amperage : 5A DC Voltage Output : 12VDC UNITS: MM Page 5...
  • Page 8 REQUIREMENTS 1) TEMPERATURE a. Operational temperature range: -25˚C to 70˚C. (-13˚F to 160˚F) b. Forced or passive venting is required on all installations to keep the cabinet temperature below 160˚F. 2) LOCATION a. Mount power supplies in the lower half of the cabinet. b.
  • Page 9 GAS PRICER SIGN SIZE DETERMINES WHICH SP POWER SUPPLY TO USE SP-150-12 SP-320-12 For use with sign sizes 6”, 8”, and 12”. For use with sign sizes 16”, 18”, 24”, 30”, and 36”. PLEASE NOTE YOUR APPLICATION TYPE BELOW AND REFER TO USAGE CHART IN SP-SECTION 3 Single-Sided Double-Sided Page 7...
  • Page 10 Make sure you received the correct SP power supply quantities for your application. SINGLE SIDED DOUBLE SIDED Gas Pricer SP-150-12 SP-320-12 SP-150-12 SP-320-12 Sign Size 6" 8" 12" 16" 18" 24" 30" 36" Page 2 Page 8...
  • Page 11 Sign Panel SP-150-12 Spare connection for Double-Sided Configuration ONLY. Your 110VAC source should not be hot until all connections are completed. Page 2 Page 9...
  • Page 12 Sign Panel 1 SP-150-12 Sign Panel 2 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 10...
  • Page 13 Decimal Panel SP-320-12 Spare connections for Double-Sided Configuration ONLY. Your 110VAC source should not be hot until all connections are completed. Page 2 Page 11...
  • Page 14 Decimal Panel 1 SP-320-12 Decimal Panel 2 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 12...
  • Page 15 Decimal Panel SP-320-12 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 13...
  • Page 16 Decimal Panel 1 SP-320-12 Your 110VAC source should not be hot until all connections are completed. Decimal Panel 2 SP-320-12 Page 2 Page 14...
  • Page 17 AC cable must be provided by installer. Use only appropriate gauge cable for the installation application as stated in the SAM manual. AC wiring is identical for both the SP-150-12 and SP-320-12. GROUND NEUTRAL LIVE Your 110VAC source should not be hot until all connections are completed. Page 4 Page 15...
  • Page 18 Please go through the following checklist before powering up the power supply(s).  The installation meets the requirements in Section 2.  Make sure all connections to the terminal blocks are secure (potential danger of short circuit).  Label your AC and DC wiring accordingly so that any service personnel can identify them easily. ...
  • Page 19 READ ME FIRST – DO’S AND DON’TS ............CLG-SECTION 1 –...
  • Page 20 DON’TS  Do not cut into the Gas Pricer PCB at any point.  Do not drill into the Gas Pricer PCB.  Do not cut/modify any part of the Gas Pricer extrusion.  Do not cut/modify any part of the Gas Pricer mounting brackets. ...
  • Page 21 READ INSTRUCTIONS  Make sure you read and understand all instructions.  Retain instructions for future reference.  Follow all warnings and instructions indicated in this wiring guide including those marked on the product. BEFORE WIRING  During installation do not allow the AC power to be connected inadvertently. DURING OPERATION ...
  • Page 22 Model: CLG100-12 AC Voltage Input : 110 ~ 120VAC AC Amperage : 0.8A DC Voltage Output : 12VDC UNITS: MM Page 20...
  • Page 23 REQUIREMENTS 1) TEMPERATURE b. Operational temperature range: -25˚C to 70˚C. (-13˚F to 160˚F) a. Forced or passive venting is required on all installations to keep the cabinet temperature below 160˚F. 2) LOCATION c. Mount power supplies in the lower half of the cabinet. a.
  • Page 24 GAS PRICER SIGN SIZE DETERMINES CLG POWER SUPPLY QUANTITY TO USE PLEASE NOTE YOUR APPLICATION TYPE BELOW AND REFER TO USAGE CHART IN CLG-SECTION 3 Single-Sided Double-Sided Page 22...
  • Page 25 Make sure you received the correct CLG power supply quantities for your application. Gas Pricer CLG-100-12 CLG-100-12 Sign Size SINGLE SIDED DOUBLE SIDED 6" 8" 12" 16" 18" 24" 30" Page 2 Page 23...
  • Page 26 Sign Panel CLG-100-12 Spare connection for Double-Sided Configuration ONLY. Your 110VAC source should not be hot until all connections are completed. Page 2 Page 24...
  • Page 27 Sign Panel 1 CLG-100-12 Sign Panel 2 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 25...
  • Page 28 CLG-100-12 Sign Panel Your 110VAC source should not be hot until all connections are completed. Page 2 Page 26...
  • Page 29 CLG-100-12 Sign Panel 1 CLG-100-12 Sign Panel 2 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 27...
  • Page 30 Decimal Panel CLG-100-12 CLG-100-12 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 28...
  • Page 31 Decimal Panel 1 CLG-100-12 CLG-100-12 Your 110VAC source should not be hot until all connections are completed. Decimal Panel 2 CLG-100-12 CLG-100-12 Page 2 Page 29...
  • Page 32 Decimal Panel CLG-100-12 x 4 Your 110VAC source should not be hot until all connections are completed. Page 2 Page 30...
  • Page 33 CLG-100-12 x 4 Decimal Panel 1 Your 110VAC source should not be hot until all connections are completed. CLG-100-12 x 4 Decimal Panel 2 Page 2 Page 31...
  • Page 34 SP - SECTION 5 AC cable must be provided by installer. Use only appropriate gauge cable for the installation application as stated in the SAM manual. Your 110VAC source should not be hot until all connections are completed. Page 4 Page 32...
  • Page 35 SP - SECTION 5 Please go through the following checklist before powering up the power supply(s).  The installation meets the requirements in CLG-Section 2.  Make sure all connections to the terminal blocks are secure (potential danger of short circuit). ...
  • Page 36 LIMITED ONE YEAR WARRANTY PRO-LITE INC. Warranty to the original consumer that each of its PRO-LITE products and all components therein contained will be free from defects in materials and/or workmanship for one year from the date of purchase or unless otherwise specified. Any warranty hereunder is extended only to the original consumer purchaser and is not assignable. Warranty Conditions In the event of malfunction or other indication of failure attributable directly to faulty workmanship and/ or material, PRO-LITE INC.
