• ENVIRONMENTAL:
Operating, 0-65° C
Storage, -40° - 80° C
R.H., 0-90% non condensing
• ENCLOSURE:
1/4 DIN, ABS plastic 96 X 96 X 150MM or Nema 4X wall mount
• FRONT PANEL:
Gasketed Nema 4X (DIN Style)
• ACCESS:
Chassis & boards remove from front of case in DIN style unit
• TERMINAL STRIP:
(40) 'Pluggable' for ease of wiring 28 – 16 AWG
• CONNECTIONS:
Removable screw terminal blocks 28 – 16 AWG wire
• CONTROL OUTPUTS:
4 digital outputs user programmable, SPDT Form 'C' relays 5 AMP, 4 solid state outputs
• ALARM ANNUNCIATION:
Multiple alarm annunciation, in graphical and alphanumeric formats with user programmable
audible alarm horn.
• PROGRAMMING:
Menu based, all parameters are user configurable via menu prompts and user keys. The
Preconfigured screens and 'pull down' sub menus with English prompts assures rapid setup
And commissioning.
• 1 YEAR WARRANTY
• M.V. NET:
Network allows multiple units to be connected together for distributed applications.
• EXPANSION CARDS:
Allow up to 4 relay outputs, 4 digital outputs, 4 analog inputs and 4 analog outputs in a single
1/4 DIN panel mountable case.

FEATURES:

• Microprocessor Based
• Graphic LCD Display
• 5 Function Keys
• Isolated 24VDC Sensor Power
• 8 Digital Inputs
