- Page 1 MYRIAD ANN2 DIGITAL ANNUNCIATOR INSTRUCTION MANUAL MYRANN2INST VISIT OUR WEBSITE SIGMACONTROLS.COM...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION…………………………………… 3 Ordering Information Specifications Features WIRING……………………………………………… 6 Dwg # 03-38 Dwg # 03-37 PROGRAMMING AND INITIAL SETUP……………. 8 Terminal Block Detail Intital Setup & Programming Overview/Key Description... -
Page 3: Introduction
INTRODUCTION: The Sigma Myriad ANN2 annunciator is a micro controller based, state of the art, 8 channel annunciator offering unmatched performance and full user configurability. The ANN2 is used with dry contact or 24VDC inputs. Alarm status indication is displayed in both alpha and graphic format on the ANN2’s graphic LCD display. -
Page 4: Features
• ENVIRONMENTAL: Operating, 0-65° C Storage, -40° - 80° C R.H., 0-90% non condensing • ENCLOSURE: 1/4 DIN, ABS plastic 96 X 96 X 150MM or Nema 4X wall mount • FRONT PANEL: Gasketed Nema 4X (DIN Style) • ACCESS: Chassis &... -
Page 5: Wiring
• Fully User Programmable in English • ‘MV Net’ Port RS 485 +User Port • ‘Pop Up’ Alarm Screens • 4 Relay Outputs • 4 Solid State Outputs • Programmable Alarm Horn • Buzzer Programmable WIRING DETAIL: • Inputs, see Dwg # 03-38 •... - Page 8 PROGRAMMING & SETUP The Myriad ANN2 utilizes ‘plain english’ menu driven setup screens which are intuitive and readily accessible. From the default screen, use the → ← keys to move the curser to the ‘PROG’ position and press ‘ENTER’. This action brings up the password entry screen. The unit password is set to ‘O’ when the unit leaves the factory.
- Page 9 has been configured press ‘ENTER’ when the ‘NEXT’ item is highlighted. This will bring up the ‘INPUT BIAS’ program screens. This allows configuration of the ‘normal’ condition of the relay and solid state outputs. In this screen an input channel can be configured to be ‘Normally Open’ or ‘Normally Closed’ when it changes state, i.e.
- Page 10 First alarm channel will flash to indicate the ‘first out’ channel. Reset is automatic when the causal condition has been removed. 3) Manual Reset First alarm channel will flash to indicate ‘first out’ channel. Alarms must be acknowledged by pressing any key.
- Page 11 In this mode each input is ‘slaved’ to an individual output. Digital inputs 1-4 will activate relay outputs 1-4 and digital inputs 5-8 will activate solid state outputs 5-8. The respective relay will activate with an alarm condition and may be reset via the ‘RESET’ key when the causal condition has been removed.
- Page 12 When the alarm horn is selected to be ‘ON’, the duration of the horn action after an alarm condition is variable. To vary the time the horn sounds upon alarm use the ↑ ↓ keys to select the required time in seconds.
- Page 13 The diagnostic screen provides a quick way to check the status of all inputs and outputs. Whenever an input or output is highlighted by the cursor, that channel is in alarm (active) and its corresponding output (when ‘per point’ output mode is selected) is also highlighted. When ‘per point’...
- Page 14 APPENDIX ‘A’ SWITCH SELECTION OF INPUT RANGES (Factory default 0-10V). The dip switches in the ANN2 should be set for 0-10V. The range dip switches are located on the bottom of the main circuit board. Disconnect power, remove two rear screws, remove terminal strips and slide the entire unit out of its case (DIN unit).
