  • Page 2 Important note Some of the information in this pamphlet has been taken from the Owner's Manual supplied with the vehicle. Therefore, any references to chapters refer to the "Owner's Manual" and must be consulted there.
  • Page 4 The main priority for emergency response personnel is to help save the Introduction lives of accident victims without exposing the victims or themselves to The SF90 STRADALE is a hybrid vehicle: traction is supplied by an further risk. This emergency response manual contains information on internal combustion engine (ICE) and three electric motors (E1, E2, E3) how quick, safe access to accident victims can be facilitated.
  • Page 5 Introduction...

  • Page 6: Table Of Contents

    Guide to extrication ........41 How to identify the vehicle ......10 Diagram of components for cutting and extrication .
  • Page 7 Loading the vehicle onto the trailer ....63 Securing the vehicle to the trailer ..... . 64 Storing a hybrid vehicle .
  • Page 9 Roadside Recovery...

  • Page 10: How To Identify The Vehicle

    How to identify the vehicle The aerodynamic lines of the SF90 STRADALE make it easy to identify. However, a collision may damage the vehicle and make identification difficult. In these circumstances, the emergency response personnel must visually inspect the vehicle to ascertain whether high voltage components are present.
  • Page 11 Power electronics (inverters) for handling the front electric motors. High voltage battery. High voltage and 12V battery charging socket. High voltage connector cables. 12V battery. Roadside Recovery...

  • Page 12: Diagram Of Hybrid System Components

    Diagram of hybrid system components Roadside Recovery...

  • Page 13: Hybrid System Precautions

    Hybrid system precautions Danger - High voltage The symbol shown below which is included in the caution notes identifies Risk of serious burns or violent electric shock resulting in injuries that the high voltage electrical parts on the vehicle that may put your safety at can be fatal.

  • Page 14: Guide To Emergency Response On A Hybrid Vehicle

    Danger - High voltage Danger - High voltage Drivers are responsible for leaving the vehicle without performing a Failure to observe the following instructions may lead to a risk of fire, KEY-OFF: drivers must always perform a KEY-OFF before getting serious injury or electric shock which may be fatal.
  • Page 15 How to approach a damaged hybrid vehicle Danger - High voltage Precautions that must be taken in any emergency situation involving a Never lift the vehicle using the bottom of the high voltage battery as a hybrid vehicle equipped with a high voltage system are listed below: point of support.

  • Page 16: Procedure For Deactivating The High Voltage System

    ● remove the vehicle from the water; Danger - High voltage ● if possible, let the water drain out of the vehicle; ● follow the procedures for stabilising the vehicle and deactivating the If the high voltage battery is damaged and/or detached from the high voltage system.

  • Page 17: Hybrid System Batteries

    ● Remove the protective cover on the LH rear side, as shown in the Procedure for deactivating the high voltage system figure. ● Remove the fuse shown in the figure with tab B. Important note This procedure may only be carried out by qualified technical personnel, who have the necessary experience, documentation and equipment to work in complete safety.
  • Page 18 12V battery Danger - High voltage The other type of battery on the vehicle is a maintenance-free sealed 12V Never carry out any operations on the batteries by yourself. Always lithium ion battery located behind the passenger-side footrest. get the F to perform any operations on the ERRARI ERVICE...

  • Page 19: Electronic Alarm

    Emergency starting From outside the vehicle, press button on the key once to activate the alarm system: Warning ● the turn indicators flash once; ● the system beeps once; The 12V battery CANNOT be used for emergency starting of the ●...
  • Page 20 or the front/rear lid is open or not closed properly and is therefore not Press button on the roof panel dome light to deactivate the anti-lift protected by the perimeter surveillance function. If this is the case, check function of the alarm system. When this function is deactivated, the LED that the doors and front/rear lids are closed properly and close any door or on the button will flash for about 3 seconds and will then turn off.

  • Page 21: Doors

    If you cannot open the door after pressing button on the key, the remote control battery may be flat. If the remote control battery is flat, use the emergency key supplied with the keys to get into the vehicle. ● Remove the cover and pull out the metal insert from the main...
  • Page 22 When the door is closed, the window automatically moves up until it WAL (Walk Away Locking) function reaches the “upper limit”. This function is used to automatically lock the doors and luggage compartment lid when the key is moved from inside the vehicle to outside. Opening the doors from outside Automatic locking occurs if the driver with the key moves at least 1.5 Use the remote control to deactivate the alarm and the central door...
  • Page 23 Opening the doors from inside Press the button shown on the inner door panel to release the lock and open the door: the window will move down to its “target position”. When the door is closed, it will move up until it meets its upper limit. If the unlock button is pressed without opening the door, the window will move down to its target position and stop and if the door is not opened within 2 seconds, the window will move back up until it meets the upper...

  • Page 24: Reactivating The Fuel Inertia Switch

    Important note Contact the F as soon as possible to correct ERRARI ERVICE ETWORK the malfunctioning. Reactivating the fuel inertia switch The fuel inertia switch is a safety device which deactivates the ICE fuel pump relays if a collision occurs. A pop-up appears on the instrument panel with a symbol and specific message, a special warning light comes on, as described in the chapter "List of symbols and warning lights on the instrument panel", and the...
  • Page 25 Important note If a collision occurs and the airbags are deployed, the fuel pump relays cannot be reactivated for safety reasons. If this occurs, contact the ERRARI ERVICE ETWORK Roadside Recovery...

  • Page 26: Disconnecting The 12V Battery

    Disconnecting the 12V battery The battery is situated behind the footrest on the passenger side. To disconnect the power supply from the battery to the low voltage electrical system, remove the cable with quick release from pin on the negative terminal of the battery. After reconnecting or replacing the 12V battery, the new component must be reintroduced to the system and all the self-adaptive parameters must be reset before starting up the vehicle.

  • Page 27: Battery Charging

    stop both batteries working properly and cause permanent damage to Battery charging them. A power lead with a control unit is supplied with the vehicle that has a PWM (Pulse With Modulation) safety system which is used to charge both Low battery charge warning the high voltage and the 12V battery and keep the charge level constant When the vehicle is stopped and a KEY-OFF performed, if the high...
  • Page 28 - Never connect the power lead to an extension lead or multiple socket Access to the power socket and do not use adaptors. The socket for connecting the supplied power lead or the charging station lead is located on the LH side of the vehicle and may vary from the one - Always place the power lead where it cannot be stepped on, damaged shown according to market requirements.
  • Page 29 Make sure that the cable is not damaged: if damaged, do not use it and contact the F to get it replaced. ERRARI ERVICE ETWORK Make sure that the vents on the back of the control unit, shown in the figure, are open and clean.
  • Page 30 After KEY-OFF with the vehicle locked using the remote control, the power lead connected and recharging in progress, the instrument panel displays the screen shown in the figure, with the charge percentages at that time and the remaining time needed to complete charging. This screen remains displayed according to the key cycle and timeout.
  • Page 31 Danger - High voltage ALWAYS check that the power lead has been disconnected before starting up the vehicle. Emergency release procedure for charge socket flap on vehicle A specific message is displayed on the instrument panel to warn the driver In case of malfunction of the charge socket flap release button.
  • Page 32 Turn the screw shown in the figure a quarter turn counterclockwise and remove the flap. Take out the green cable and pull it to release the charge connector. Important note If the emergency procedure has to be used frequently, have the device checked by the F ERRARI ERVICE...

  • Page 33: High Voltage And 12V Battery Charging Socket

    Before charging the batteries, wait for the message to appear. Warning The emergency manual release procedure may only be carried out by a specialised service centre technician. In an emergency, contact a centre. ERRARI ERVICE ETWORK Charging system failure warnings If the plug-in charge system malfunctions, a message on the instrument panel will inform the user and suggest which checks and/or actions should be carried out to resolve the problem.

  • Page 34: Engine Compartment Lid

    Emergency opening of charge flap Closing the charge flap If the flap does not open when the button on the driver-side door panel After removing the power lead plug from the vehicle socket, put on the is pressed, this condition is indicated by a pop-up and symbol on the protective cap.

  • Page 35: Luggage Compartment Lid

    Pull the support rod down and put the end in the special slot on the frame, Luggage compartment lid as shown in the figure. Opening The luggage compartment can be opened from both outside and inside the vehicle. When outside the vehicle, press the button indicated on the key fob twice within 5 seconds.
  • Page 36 Warning Only open or close the luggage compartment lid when the vehicle is stationary. Warning Before opening or closing the luggage compartment lid, make sure there are no persons, animals or objects in the immediate vicinity. Emergency Opening If the luggage compartment lid release button on the driver-side door Important note panel does not work, there is a string for manual emergency opening underneath the dashboard to the left of the steering wheel as shown by...

  • Page 37: Fuel Filler Neck

    Fuel filler neck Capless filler neck This vehicle has a capless fuel filler. This system allows you to refuel by simply placing the nozzle in the filler neck without having to unscrew a Warning cap and screw it up again. See the specific pamphlet for more details. Refuelling in enclosed areas is not allowed.
  • Page 38 Turn the screw shown in the figure a quarter turn counterclockwise and the acoustic signal is emitted, you must do the following to continue to remove the flap. refuel: ● close the fuel filler flap; Pull the red cable shown in the figure to manually release the fuel filler flap.
  • Page 39 Warning If the conditions that allow refuelling are not met or the system that controls the opening of the fuel filler flap is faulty, pop-up messages indicating that refuelling is not available or malfunctioning will be displayed on the instrument panel. Roadside Recovery...

  • Page 40: Fuel Filler Flap Emergency Opening Device

    Fuel filler flap emergency opening device To release the closing device and manually open the fuel flap, pull the cable indicated on the RH rear side of the engine compartment. Roadside Recovery...

  • Page 41: Guide To Extrication

    Guide to extrication Danger - High voltage When arriving on the scene of an accident, emergency response personnel If vehicle components have to be removed, DO NOT touch any of the must follow their standard procedures for car accidents. high voltage system components or the high voltage cables. there is a risk of serious and even fatal injury.

  • Page 42: Diagram Of Components For Cutting And Extrication

    Diagram of components for cutting and extrication Roadside Recovery...

  • Page 43: Using The Electric Parking Brake - Epb

    Using the electric parking brake - EPB Warning Using the electric parking brake Always apply the parking brake when the vehicle is parked. The vehicle The parking brake acts on the rear discs using brake callipers operated by should be blocked. If this is not the case, please contact the F ERRARI an electric actuator.
  • Page 44 - the external and internal rearview mirrors are in the correct position. Check the following at regular intervals and always before long trips: ● tyre pressure and condition; ● levels of fluids and lubricants on the engine; ● condition of windscreen wiper blades; ●...

  • Page 45: Starting The Vehicle

    Starting the vehicle Important note The buttons on the dashboard, steering wheel, roof panel dome light and doors are touch buttons with haptic feedback. To execute a command, press the button until you get feedback in the form of a slight vibration and the indication or symbol changes status.
  • Page 46 “Key-Less” ignition system The F keys use a Key-less start system (see also the specific ERRARI warning sheet) which can be used to perform a KEY-ON switch and then start the electric motors or the engine by simply placing the key inside the vehicle in the vicinity of the driver zone.

  • Page 47: Starting The Vehicle

    alarm and unlock the doors; in this way, the ENGINE START function Gearbox mode at start-up can be used again. This occurs even if the anti-theft system activation and door locking command is given by a key outside the vehicle when Important note a second key is inside.

  • Page 48: Using The Gearbox

    Using the gearbox Warning Using the gearbox in “Manual” mode If the “UP” and “DOWN” paddles are not working, a pop-up will To set the gearbox "Manual" mode, pull the central lever of the gearbox appear on the instrument panel with the message “Depress brake pedal selector on the centre console onto M and release it so that it goes back and press LAUNCH to engage gear”.
  • Page 49 In any event, it is advisable to: DOWN ● shift gears without releasing the accelerator pedal if pressed; ● Wait until gearshifting has been completed before requesting the next shift, avoiding a rapid sequence of multiple requests. UP-shifting due to overrevving The system automatically selects a higher gear if the accelerator pedal is pressed and the engine approaches the “runaway speed rate”...
  • Page 50 The DOWN-shift request from the paddle is ignored if gearshifting is When “Automatic” mode is selected, the system automatically shifts already in progress due to engine under-revving. UP and DOWN in relation to vehicle speed, engine speed and the torque/power requested by the driver. Sequential downshifting When in “Automatic”...

  • Page 51: Selecting Reverse Gear - R

    Reverse gear must always be selected when the vehicle is stationary and “N” (Neutral) request the brake pedal pressed. In any driving modes (electric or hybrid), pull both UP and DOWN paddles towards the steering wheel at the same time without pressing the brake pedal to request neutral “N”.
  • Page 52 The hybrid system traction units can also be switched off in this way Warning with the gearbox either in “N” or with a gear engaged. After the ENGINE STOP function has been activated, the instrument panel NEVER leave the vehicle without activating the ENGINE STOP remains on for a few seconds and indicates which gear is engaged.
  • Page 53 °C 22:38 Roadside Recovery...

  • Page 54: Dimensions And Weights

    Dimensions and weights   Wheelbase 2650 mm Max. length 4710 mm Max. width 1972 mm Max. width (with rear-view mirrors 2299 mm unfolded) Max. height 1226 mm Front track 1679 mm Rear track 1652 mm Front overhang 1213 mm Rear overhang 842 mm Front ramp angle 9°...
  • Page 55 1 2 1 3 2 6 5 0 8 1 1 4 6 7 4 1 6 7 9 1652 2 2 9 9 1972.5 Roadside Recovery...

  • Page 56: Tool Bag And Tyre Inflation And/Or Repair Kit

    Tool bag and tyre inflation and/or repair kit The tool bag, emergency tyre inflation and repair kit and kit with the battery charger lead are kept in the luggage compartment. Roadside Recovery...

  • Page 57: In Case Of A Tyre Puncture

    In case of a tyre puncture Warning Useful accessories Damage to the wheel that causes air leaks cannot be repaired. Do not In addition to the tools supplied with the vehicle, the hazard warning remove foreign objects (screws or nails) that have penetrated the tyre. triangle and fluorescent safety jacket should always be kept on board in order to signal hazardous situations in compliance with traffic regulations.
  • Page 58 event of an allergic reaction, seek immediate medical advice. Store the Warning bottle in the bag in the luggage compartment away from sources of heat. If pressure has dropped to below 1.8 bar, stop driving: the kit cannot guarantee the correct hold because the tyre is too damaged. Contact the The liquid sealant has an expiry date: the expiry date is indicated on the kit bottle.

  • Page 59: Replacing A Wheel

    Environment STANDARD RUN FLAT Maintaining correct tyre pressure helps to improve tyre rolling and reduce fuel consumption. Replacing a wheel 0 bar - 0 psi Warning 0 bar - 0 psi The procedure to change a wheel is very delicate and must only be performed by expert personnel using the necessary tools.
  • Page 60 Warning Warning Use of the tow hook provided is only allowed in an emergency to load Do not use the levers, suspension and wheel rims but only the tow hook the vehicle onto the ramp of a breakdown truck or trailer. properly fitted in place.

  • Page 61: Emergency Release Of The Electric Parking Brake - Epb

    - if there is a Park Lock failure (the following message is shown on the Emergency release of the electric parking brake - EPB instrument panel: “Only manual unlock gearbox allowed: See manual”. This procedure is required when the electric release button cannot open the EPB callipers and a warning light and pop-up appears on the instrument panel with the special symbol and the message "EPB failure.

  • Page 62: Lifting The Vehicle

    ● Open the engine compartment lid. If the vehicle has to be lifted following an accident or in order to carry out emergency repair work, we recommend passing on the following ● Insert the wrench/extension into the opening on the trim panel in information to the people who will be carrying out the work.
  • Page 63 ● Attach the winch cable to the tow hook to pull the vehicle onto the trailer. Warning DO NOT attach the winch cable to other parts of the vehicle. Warning DO NOT pull the vehicle onto the trailer using only the tow hook but lift it using the special straps.
  • Page 64 ● Once the vehicle has been secured to the trailer, remove the key. and tools and Ferrari S.p.A. shall not be held liable for any work that is performed using these technical information bulletins incorrectly. Storing a hybrid vehicle...
  • Page 65 Roadside Recovery...
  • Page 67 INDEX...
  • Page 68 INDEX Hybrid system precautions ..... . . 13 In case of a tyre puncture ......57 Battery charging .
  • Page 69 Storing a hybrid vehicle ......64 Switching off the engine and vehicle system ... . 51 Towing .
  • Page 70 Edition 1, July 2020 Catalogue no. 6896/20 Technical Service Department ERRARI Via Abetone Inferiore 4, 41053 Maranello (MO) - Italia...
