- Page 1 COBRA HEAD 150 User Manual...
-
Page 2: Table Of Contents
T able of Contents Safety ..................2 Important Safety Instructions ............3 Precautions..................4 Suspension ..................4 Mounting ..................4 Description ................5 ................Features Setup ..................6 ..............Power Linking ................Operation ................Menu Map ..............DMX Channel Specifications................8... -
Page 3: Safety
Safety Important Safety Information WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OVEREXPOSE THIS FIXTURE TO RAIN OR MOISTURE. WARNING: CONNECT ONLY TO MAINS POWER SUPPLY WITH A PROTECTIVE EARTHING CONNECTION. WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THE REAR COVER OR ATTEMPT TO OPEN THE LIGHTING FIXTURE. -
Page 4: Precautions
Precautions If an AVE lighting fixture is used outdoors on a sunny day, ensure that it is in a shaded area and is well ventilated to help prevent overheating. Do not use AVE lighting fixtures in environments that are below 0°C OR exceed +40°C. -
Page 5: Description
The Cobra Head 150 can be mounted on a flat surface or upside down using the included hanging bracket and safety loop. The digital display can also be inverted when hung making it easier to navigate the menu. -
Page 6: Setup
4. Select the desired operation mode and press ‘enter’ 5. Wait approx. 10sec for the setting to take effect Operation To access the menus and functions of the Cobra Head 150, use the four (4) buttons located under the main LCD control screen. Button Label... -
Page 7: Menu Map
Menu Map Main Level Program Level Description Addr 1 – 512 DMX Address Value Chnd 9 Channel DMX Mode 11Ch 11 Channel DMX Mode SLNd NASt Master SLA 1 Slave 1 SLA 2 Slave 2 ShNd Sh 1 Show 1 Sh 2 Show 2 Sh 3... -
Page 8: Dmx Channel
Specifications Light Source: 1x 35W White LED (50,000hr life expectancy) Beam Angle: 12° Gobo Wheel: 7 + open (fixed) Colour Wheel: 7 + white split colours, scroll at variable speeds Illuminace: (12°): 2,400 lux @ 5m Pan Range: 540° Tilt Range: 270° Strobe Rate: 0 –...
