- Page 1 ITEM NO.:A101012100 WE HAVE YOU IN MIND, LET US SERVE YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com 1-(866)-578-6569 Country of Origin: China Production Number: xxxxxxxxxx...
-
Page 2: Safety Information
2 / 8 Safety Information Two people are required for this This unit is heavy! Do not assemble DANGER: assembly. this item alone. Some parts may contain sharp edges. Wear protective gloves. Do not leave the gazebo where there WARNING: When assembling and using this product, is a risk of high wind, as possible damage will basic safety precautions should always be... -
Page 3: Parts List
3 / 8 Parts List Description Label Part# Image Screen 1 P006300073 Screen 2 P006300074 Short across P000400868 beam Long across beam P000400870 Long across beam P000400869 Slanting beam P000601308 upper tube Middle beam P000601309 （Long） Middle beam P000601310 （Short） Big top P000501141 connector... -
Page 4: Hardware Pack
4 / 8 Hardware Pack 1 Label Description Part# Image M6X15 Bolt H010020011 4PCS M6 flat washer H050010023 48PCS M6X30 Bolt H010020023 28PCS M6 nut H040010003 16 PCS M6 Wrench 2 PCS H090010008 Country of Origin: China... - Page 5 5 / 8 Fig.1：Attach screen1（A）to screen2 （B） ，then fix by using Bolt（CC）and Flat washer（BB）. Fig.2：Insert Long across beam 1(D) into Long across beam 2(E) then fix by using Bolt（AA） and Flat washer（BB）. Fig.3：Attach the across beam（C/D/E）to screen（A/B）fix by using Bolt（CC）and Flat washer （BB）nut（DD）...
- Page 6 6 / 8 Fig.7：Insert Middle beam(G/H) to Big top connector(J). Fig.8： Attach Connector for Slanting Beam （G/H） to across beam fix by using Bolt （AA） and Flat washer （BB）.then Put big canopy（Q）on big top frame( Do not fasten corner)。 。 Fig.9：Insert Adjust tube(K) to Slanting beam upper tube(F)，then Adjust the Adjust tube(K) to the minimum.
- Page 7 7 / 8 Fig.10：Put small canopy（R）on small top frame. Fix small canopy four corner to adjustable tube， then adjust the tube to right position until small canopy tight. Fig.11: Fix big canopy four corner then Attach Finial(P) to the top. Fig.12：by using stake“7”(FF) fix assembled gazebo on ground.
-
Page 8: Care And Maintenance
Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of 6 months from the date of purchase, provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes.
