Avalon 10X10 ft Canopy
Instruction Manual
Item #: L-GZ816PST
SKU #: 810213581
If you have any issues with this product, do not return
the product back to the store!
For any questions or concerns about our product, please
Contact Sunjoy Customer Service
1(866) 578‐6569
8:00 AM EST – 8:00 PM PST
For further assistance, please write to us at
biglots@sunjoygroup.com
Production Number: 20184434
Advertisement
Related Manuals for Sunjoy Avalon L-GZ816PST
Summary of Contents for Sunjoy Avalon L-GZ816PST
- Page 1 If you have any issues with this product, do not return the product back to the store! For any questions or concerns about our product, please Contact Sunjoy Customer Service 1(866) 578‐6569 8:00 AM EST – 8:00 PM PST For further assistance, please write to us at biglots@sunjoygroup.com...
- Page 2 IMPORTANT: KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE. WARNING: 1. Two people are required for assembly. 2. Some parts may contain sharp edges. We recommend that that you wear protective gloves. 3. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of personal injury or damage.
-
Page 3: Parts List
Parts List Part NO# Description Image Upper post 4 PCS Down post 4 PCS Long support pipe 8 PCS Short support pipe 4 PCS Top short pipe 4 PCS Top long pipe 4 PCS Base 4 PCS Pipe connector 4 PCS Big top connector 1 PC Small canopy... -
Page 4: Assembly Step
Assembly Step Fig.1: Insert both ends of short support pipe (4) into long support pipe (3), and then insert another end of long support pipe (3) into pipe connector (B), with gradient circular tube upwards. Fig.2: Insert one end with contracted pipe of top short pipe (5) into top long pipe (6), then insert top long pipe (6) into big top connector (C), put big canopy (E) onto frame before installing fourth top long pipe (6), do not spread out. - Page 5 Fig.4: Insert one end with spring fastener of upper post (1) into pipe connector (B). Fig 5: Insert one end with contracted pipe of down post (2) into upper post (1); insert another end of down post (2) into base (A).
- Page 6 Fig 6: At last, unfold the big canopy (E); put hooks of the canopy four corners into holes of down posts. Then attach the ring on the canopy to the hook on the base (A) to secure the canopy as Fig 6 showed.
-
Page 7: Limited Manufacturer's Warranty
· Periodically check and ensure that all bolts are well-tighten during use Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of 1 year from the date of purchase, provided the item was factory‐sealed at the time of purchase and is maintained with care and used only for...
