Mechanics Hoists
This operation manual is intended as an instruction manual for trained
personnel who are in charge of installation, maintenance, repair etc.
Before equipment use, please read this operation manual
Mechanics Hoists
Model MH
2721 NE 4th Ave Pompano FL 33064| (954) 367-6116
OPERATION MANUAL
carefully.
Version # MH-0214
Visit WWW.ACIHOIST.COM for the most current information
PAGE: 1
MH-0214

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MH and is the answer not in the manual?

Questions and answers

Summary of Contents for ACI Hoist & Crane MH

  • Page 1 This operation manual is intended as an instruction manual for trained personnel who are in charge of installation, maintenance, repair etc. Before equipment use, please read this operation manual carefully. Version # MH-0214 Mechanics Hoists PAGE: 1 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 2 Mechanics Hoists PAGE: 2 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 3: Table Of Contents

    8.0 WIRING DIAGRAM ..............................23 9.0 DIMENSIONS & SPECIFICATIONS ........................24 10.0 EXPLODED VIEWS & PARTS LISTS........................26 Mechanics Hoists PAGE: 3 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 4 10.1 Repair Parts – Ordering Instructions ......................26 10.2 Exploded View: MH-005 & MH-010 ......................27 10.3 Exploded View: MH-020 ..........................28 10.4 Parts List: MH-005, MH-010, & MH-020 .......................29 10.5 Exploded View: MH Pendant ........................32 10.6 Parts List: MH Pendant ..........................33 Mechanics Hoists...
  • Page 5: Warranty

    DO NOT use equipment to lift, support or otherwise transport people. DO NOT suspend unattended loads over people. Mechanics Hoists PAGE: 5 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 6: Safety Precautions

    Failure to read and comply with any of the limitations noted in this manual can result in serious bodily injury or death, and/or property damage. Mechanics Hoists PAGE: 6 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 7: Installation

    As a minimum, the system should be rated for 20 amps and the system should have #14 AWG or larger, wiring. Mechanics Hoists PAGE: 7 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 8: Connection To The Electrical Supply

    Only use Lubriplate Bar and Chain Oil 10-R or equal lubricant as a lubricant for the load chain. Mechanics Hoists PAGE: 8 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 9: Chain Container

    1. Remove both bolts from the chain container mounting bracket (see Figure 3.9.1.1). 2. Attach the chain container to the bracket. 3. Reinsert the bolts. Figure 3.9.1.1 Mechanics Hoists PAGE: 9 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 10: Operation

    Inspect all load suspension members for damage prior to use and replace or repair all damaged parts. Mechanics Hoists PAGE: 10 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 11: Operation Personnel

    DO NOT operate unless load is centered under the hoist properly.  DO NOT apply the load unless load chain is properly seated in the chain sprocket(s). Mechanics Hoists PAGE: 11 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 12: Product Cautions

    DO check brake function by tensioning the hoist prior to each lift operation.  DO lubricate load chain per hoist manufacturer’s recommendations.  DO use Mechanics Hoist MH recommended parts when repairing the hoist unit. Mechanics Hoists PAGE: 12 Model MH...
  • Page 13  DO make sure the hook travel is in the same direction as shown on the controls. Mechanics Hoists PAGE: 13 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 14: Inspection

    Severe Service – Quarterly  Special or Infrequent Service – As recommended by a qualified person before the first occurrence. Mechanics Hoists PAGE: 14 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 15: Frequent Inspection

    11. Check to ensure there is no electrical apparatus for signs of pitting or any deterioration of visible controller contacts. Mechanics Hoists PAGE: 15 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 16: Occasionally Used Hoist

    They Clean/Lubricate, or replace as required (swivel bearing) should be free of dirt, grime and Mechanics Hoists PAGE: 16 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 17 Depressing and releasing push Pendant (switches) Function Repair or replace as necessary buttons should make and break Mechanics Hoists PAGE: 17 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 18: Chain Inspection

    For this reason, cut replaced chain into short lengths to prevent use after disposal. Mechanics Hoists PAGE: 18 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 19: Maintenance And Repair

    Use of commercial or other manufactures’ chain and parts to repair MH Hoists may cause load loss. Use only factory supplied replacement load chain and parts. Chain and parts may look alike, but factory original chain and parts are made of specific materials or processed to achieve specific properties.
  • Page 20: Replacing Gear Brakes & Oil

    Pour CPC E.P. Lubricant MD 180 and Grease NLGI according to the following chart. Figure 6.3.1 Table 6.3.1 Model Grease NLGI (qt) Oil HD680 (qt) Total (qt) MH-010 & MH-020 1/16 qt 1/16 qt 1/8 qt Mechanics Hoists PAGE: 20 Model MH...
  • Page 21: Testing

    The lubricants used for the Mechanics Hoist MH may contain hazardous materials that mandate specific handling and disposal procedures. Handle and dispose of lubricants only as directed in applicable material safety data sheets and in accordance with applicable local, state and federal regulations.
  • Page 22: Troubleshooting

    Broken conductor in pendant cord. Replace the entire pendant cord if pendant cord continuity is not constant. Mechanics Hoists PAGE: 22 Model MH MH-0214 2721 NE 4th Ave Pompano FL 33064| (954) 367-6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 23: Wiring Diagram

    8.0 WIRING DIAGRAM Mechanics Hoists PAGE: 23 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 24: Dimensions & Specifications

    Motor Brush Dimensions “B” Dimension (inch) Capacity (Ton) Discard ¼ to 1 0.24 Mechanics Hoists PAGE: 24 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 25 * Chain wear will occur in section of chain that passes thru the sheave. Mechanics Hoists PAGE: 25 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 26: Exploded Views & Parts Lists

    Use of commercial or other manufactures’ chain and parts to repair MH Hoists may cause load loss. Use only factory supplied replacement load chain and parts. Chain and parts may look alike, but factory original chain and parts are made of specific materials or processed to achieve specific properties.
  • Page 27: Exploded View: Mh-005 & Mh-010

    10.2 Exploded View: MH-005 & MH-010 Mechanics Hoists PAGE: 27 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 28: Exploded View: Mh-020

    10.3 Exploded View: MH-020 Mechanics Hoists PAGE: 28 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 29: Parts List: Mh-005, Mh-010, & Mh-020

    10.4 Parts List: MH-005, MH-010, & MH-020 PARTS LIST MODEL MH Model MH-005 / MH-010 Model MH-020 ITEM PART DESCRIPTION Part No. Part No. SCREWS MH001 MH001 MOTOR COVER MH002 MH002 BEARING MH003 MH003 ROTOR MH004 MH004 AIR GUIDING IRON COVER...
  • Page 30 MH077 PRESS DISK TYPE SPRING MH078 MH078 NUTS FIXING SHEET MH079 MH079 Mechanics Hoists PAGE: 30 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 31 MH093 MH093 CABLE SET OF CONTROL SWITCH MH094 MH094 FUSE MH095 MH095 Mechanics Hoists PAGE: 31 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 32: Exploded View: Mh Pendant

    10.5 Exploded View: MH Pendant Mechanics Hoists PAGE: 32 Model MH MH-0214 ACI Hoist & Crane | 2721 NE 4th Ave Pompano Beach, FL 33064| 954.367.6116 Visit WWW.ACIHOIST.COM for the most current information...
  • Page 33: Parts List: Mh Pendant

    10.6 Parts List: MH Pendant PARTS LIST FOR PENDANT ITEM PART DESCRIPTION PART NO. CONNECTOR PBS-1PH-1 SWITCH CABLE PBS-1PH-2 SCREWS PBS-1PH-3 PLASTIC COVER PBS-1PH-4 TUBE PBS-1PH-6 STICKER PBS-1PH-7 PLASTIC COVER PBS-1PH-9 SCREWS PBS-1PH-10 SCREWS PBS-1PH-11 INTERIOR CONNECTOR PBS-1PH-12 PLASTIC COVER...
