Sealey MAC2300 Instructions

thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to
instruction
manual
1. SAFEty
‰
WARNING! read operation instructions before use. suitable for 12V operation only.
8
dO NOt leave the unit unattended while in operation.
Check capacity and maximum inflation pressure of inflatable before commencing inflation.
9
Monitor the pressure gauge while in operation.
9
The gauge should be used as an indication of pressure only. We recommend the use of a dial pressure gauge for definitive reading.
9
9
locate compressor on an appropriate surface for use.
WARNING! This compressor is capable of producing a high pressure. dO NOt inflate any item beyond its maximum
‰
capacity.
The 12V auxiliary plug must not be substituted with any other type of plug or electrical supply.
9
8
dO NOt direct inflation hose connector head at yourself, others or animals.
8
dO NOt carry by the hose, or yank the hose from an inflation valve.
8
dO NOt pull the power cable from the vehicle accessory socket by the power lead.
8
dO NOt get the compressor wet or use in the rain.
8
dO NOt use the compressor for a task it was not designed to perform.
8
dO NOt operate the compressor when you are tired, under the influence of alcohol, drugs or intoxicating medication.
8
dO NOt operate the compressor if any parts are missing as this may cause failure or possible personal injury.
8
dO NOt open the unit.
Keep children and non essential persons away from the inflation area.
9
Keep the compressor clean and in good condition.
9
Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the
9
warranty.
2. INtROduCtION
Housed in rugged composite case. Suitable for inflating tyres on cars, vans and 4x4s. Powered by a reliable, heavy-duty motor. Integral gauge
reads up to 20bar/300psi. Supplied with plug for use in vehicle accessory socket. Accessory kit, containing Presta type adaptor, ball spike and two
inflatable adaptors included in storage compartment.
3. SPECIFICAtION
e
model no: ...................................................................MAC2300
Hose length: ..................................................................900mm
Power cord length: ............................................................ 4mtr
Airflow: ..........................................................................0.75cfm
max. working pressure: .................................................. 200psi
max. pressure: ................................................................ 300psi
operating voltage: .............................................................. 12V
typical inflation time: .............. 0-30psi in 3.38min (175/70R13)
4. OPERAtION
‰
WARNING! ensure you have read and understood the safety instructions.
4.1. Place the compressor on a sound, flat surface ensuring that the inflation air hose can reach the tyre valve.
4.2. Push the universal quick-connector fully onto the inflation valve stem, and lock with the connector lever.
IMPORtANt: inflation will only be effective if the connector head is fully fitted and locked onto the valve.
4.3. Check the pressure gauge to determine the amount of pressure already in the tyre. The gauge can be used without switching the unit on.
We recommend however the use of a dial pressure gauge for a definitive reading.
4.4. Check that the compressor on/off switch is in the off position and plug the compressor into the vehicle accessory socket.
4.5. Switch the compressor on. View the pressure gauge to determine when the correct pressure has been achieved. Switch the compressor
off to stop the supply of air.
4.6. Unlock and remove the quick-connector from the inflation valve, ensuring you do not lose any air in the process.
Replace the dust cap onto the valve. When you have finished using the compressor, disconnect it from the vehicle accessory socket and
store it in a safe, dry location.
© Jack sealey limited
instructions for
AIR COMPRESSOR 12V hEAVy duty
MAC2300
model no:
Original Language Version mAC2300| Issue:6 (L) 23/08/17
