Installation

Connecting the electricity
Danger to life due to electric shock!
Improper assembly and installation of the device can lead to life-threatening electrical vol-
WARNING!
tages.
− Have assembly and connection performed by a qualified electrician only.
Personal:
•
Qualified electrician
Materialien:
• DIN rail (15 mm x 7.5 mm)
• DIN rail (15 mm x 12.5 mm)
Prerequisite:
• The terminals for the flexible wires must have a cross-section between 1 mm² and 2.5 mm².
Fig. 4: Installation on a DIN rail
1. Place the channel extension on the DIN rail (Fig. 4) from above and press it back until it locks into
place.
