Interface
The configured programmes are sent from the DIN-rail timer to the channel extension via the Bluetooth
connection.
The channel extension automatically synchronises the date and time when there is an active connection
to the DIN-rail timer.
Display and control elements
Fig. 2: Display layout
1 Channel
2 Bluetooth symbol
3 Summer/winter time
4 Function displays of the buttons on the right
5 Menu button
6 Bluetooth button
7 Reset button
8 Buttons on the left
9 Function displays of the buttons on the left
