- Page 1 Vision Components The Smart Camera People VC40XX Hardware manual Hardware Specifications for VC40XX Cameras Revision 1.5 August 2005 Document name: VC40XX_HW.pdf © Vision Components GmbH Ettlingen, Germany © 1996-2005 Vision Components GmbH Ettlingen, Germany...
- Page 2 Foreword and Disclaimer This documentation has been prepared with most possible care. However Vision Components GmbH does not take any liability for possible errors. In the interest of progress, Vision Components GmbH reserves the right to perform technical changes without further notice.
-
Page 3: Table Of Contents
Programming VC40XX Smart Cameras Programming the additional Serial Interface Appendix A: Block diagram VC40XX Smart Cameras Appendix B: Overall Dimensions Housing VC40XX Appendix D: Drawing Camera Head VC40XX Appendix E: Spectral Transmission of IR Filter Index © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 4: General Information
The VC40XX family will be extended to match the feature variety of the VC20XX series in order to offer the right camera for your application. © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 5: Basic Structure
L2 cache on chip. Its high speed 64-channel DMA controller gives additional performance. The DSP uses fast external SDRAM as main memory. A flash EPROM provides non-volatile memory. See Appendix A: Blockdiagram VC40XX Cameras © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 6: Technical Specifications Vc40Xx
Video output: RGB, 3x75 Ohm, 1 Vpp, SVGA output, HSYNC, VSYNC separate Horizontal frequency: 48.08 (VESA standard) Vertical frequency: 72.19 (VESA standard) Resolution SVGA: 800x600 (VESA standard) Pixel frequency: 50.0 MHz (VESA standard) © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 7: Technical Specifications Vc4065
Video output: RGB, 3x75 Ohm, 1 Vpp, SVGA output, HSYNC, VSYNC separate Horizontal frequency: 48.08 (VESA standard) Vertical frequency: 72.19 (VESA standard) Resolution SVGA: 800x600 (VESA standard) Pixel frequency: 50.0 MHz (VESA standard) © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 8: Technical Specifications Vc4066
RGB, 3x75 Ohm, 1 Vpp, SXGA output, HSYNC, VSYNC separate Horizontal frequency: 63.98 kHz (VESA standard) Vertical frequency: 60.02 kHz (VESA standard) Resolution SVGA: 1280 x 1024 (VESA standard) Pixel frequency: 108 MHz (VESA standard) © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 9: Vc40Xx Camera Interfaces
The pin assignments, electrical specifications as well as available accessories are shown for each interface connector in the following sections. Please also refer to the Product/Hardware/ Order Numbers for VC40XX Accessories/Cables page an up to date list of cables and further information available. © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 10: Lan / Ethernet Interface
Pin (to PC) Cable Color Cable Color 20m patch cable 10m patch cable yellow white/pink orange pink white/green white/green green green Refer to section 5 for a list of available cables with order numbers. © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 11: Trigger-/ V24 (Rs232)-/ Keypad Interface
Note that the color coding for both cables has been chosen according to the VC20XX core colors. For this reason the core colors of serial and trigger cables do not correspond to the same pin! © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 12: V24 (Rs232) Serial Cable
2x HR10A-7J-6S, female socket Cable length: 0.5m The color coding of this cable corresponds to the Trigger Cable described above. Refer to section 5 for a list of available cables with order numbers. © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 13: Electrical Specifications Of Trigger- / Serial-/ Keypad Interface
GND, Pin 3 The 1kΩ internal pull down resistor is not included in the initial hardware release (delivery until end of 2005). Please provide external pull down resistor in case the trigger input stays high. © 1996-2005 Vision Components GmbH Ettlingen, Germany... - Page 14 GND, Pin 3 (VC20XX and VC40XX) Trig In - Pin 1 (VC20XX only!) The trigger input circuit shown above can be used to connect both – the VC20XX and VC40XX smart camera families. © 1996-2005 Vision Components GmbH Ettlingen, Germany...
- Page 15 Note that the 100 Ω Resistor protecting the +5V output of the VC20XX series has been replaced with a self resetting poly fuse (see the following drawing). © 1996-2005 Vision Components GmbH Ettlingen, Germany...
-
Page 16: Power Supply And Io Interface
There are different options for the connection of the power supply: • Single voltage, with or without PLC signals, no shutdown • Dual voltage, with or without PLC signals, shutdown © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 17: Available Accessories / Cables For Power Supply And Io Interface
Available Accessories / Cables for Power Supply and IO Interface Equipped on one end with a Hirose plug jack, length 5m, 10m or 25m Refer to section 5 for a list of available cables with order numbers. © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 18: Video Output Interface
Equipped on one end with a Hirose plug, length 5m, 10m and 25m. Please order "with 2nd connector", if you need a DSUB15 connector at the other end. Refer to section 5 for a list of available cables with order numbers. © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 19: Accessories
HRS connector male 6 pin without connector 5m Trigger-Cable / C6 VK000115 HRS connector male 6 pin without connector 10m Trigger-Cable / C6 VK000164 HRS connector male 6 pin without connector 25m Trigger-Cable / C6 VK000153 © 1996-2005 Vision Components GmbH Ettlingen, Germany... - Page 20 HRS female 12 pin 5m Power / PLC-Cable C6 VK000008 10m Power / PLC-Cable C6 VK000114 HRS female 12 pin without connector 25m Power / PLC-Cable C6 VK000161 HRS female 12 pin without connector © 1996-2005 Vision Components GmbH Ettlingen, Germany...
- Page 21 25m SVGA-cable VK000065 25m SVGA-cable with HRS connector male 10 pin HD-SUB 15 pin male VK000098 DSUB 25m SVGA-cable with HRS connector male 10 pin HD-SUB 15 pin female VK000082 DSUB © 1996-2005 Vision Components GmbH Ettlingen, Germany...
- Page 22 80 mm length,20 core EK000322 200 mm length,20 core EK000629 1000 mm length,20 core EK000631 18000 mm length,20 core EK000630 Please also refer to the VC website www.vision-components.com for an up to date list of accessories. © 1996-2005 Vision Components GmbH Ettlingen, Germany...
-
Page 23: Programming Vc40Xx Smart Cameras
RS485 serial I/O\n"); tty = fopen("kbd:", (void *)0); /* open RS485 io_ioctl(tty,IO_IOCTL_SERIAL_SET_BAUD,&xbaud); write(tty,"abcdefg",7); rs232rcv(); while(c != 0x1b) c=rs232rcv(); // c=io_fgetc(tty); io_fputc(c, tty); c=io_fgetc(tty); rs232snd(c); fclose(tty); /* close RS485 © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 24: Appendix A: Block Diagram Vc40Xx Smart Cameras
VC40XX.pdf – Hardware Documentation VC40XX Smart Cameras Appendix A: Block diagram VC40XX Smart Cameras © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 25: Appendix B: Overall Dimensions Housing Vc40Xx
VC40XX.pdf – Hardware Documentation VC40XX Smart Cameras Appendix B: Overall Dimensions Housing VC40XX © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 26: Appendix D: Drawing Camera Head Vc40Xx
VC40XX.pdf – Hardware Documentation VC40XX Smart Cameras Appendix D: Drawing Camera Head VC40XX © 1996-2005 Vision Components GmbH Ettlingen, Germany... -
Page 27: Appendix E: Spectral Transmission Of Ir Filter
If the IR filter is not to be used, please order your camera with a clear glass filter or contact Vision Components for obtaining a glass filter. The order numbers for the clear glass filter is:... -
Page 28: Index
Trigger-/ V24 (RS232)-/ Keypad Interface..11 pin assignments..........9 TTL trigger input..........13 VCRT .............. 4 Trigger Input..........13 Video Output Cable........21 Trigger Output..........13 Video Output Interface ........18 Plug Assigment Y-Cable ............12 Keypad ............11 © 1996-2005 Vision Components GmbH Ettlingen, Germany...
