Bucket sink GUB3
Art. no.
GUB3
GTIN
7393069023114
Overall dimension in mm
Depth in mm
Bowl dim. in mm
Material
Material thickness in mm
Installation height in mm
Product load in N
Gross weight in kg
Weight, pallet
Pcs per pallet
www.intra-teka.com
SATIN
455 x 340 x 412
217
400 x 290 x 217
AISI 304
0,9
600
1000
4.50
135.40
24
445
5,35
172,50
172,50
375
148
FDV Revision 20200210
Description
Bucket sink in stainless steel for wall mounting.
Supplied with wall panel, Ø100mm grated waste and
a bucket grid. Waste and wall bracket in mounted onto
the sink from the supplier.
Installation
Waste and wall bracket are pre-mounted on the sink
by the supplier. Fasten the mounting description to
the wall and drill holes and fasten the sink
accordingly. Secure the wall panel to sink and wall.
455 ±2
400
123
