- Page 1 VL303ex chisel SCALER operations and maintenance manual www.trelawny.co.uk www.trelawny.co.uk...
-
Page 2: Table Of Contents
Your new Trelawny SPT tool will more than satisfy your expectations. It has been manufactured under stringent Trelawny SPT Quality Standards to meet superior performance criteria. You will find your new tool easy and safe to operate, and, with proper care, it will give you many years of dependable service. -
Page 3: Declaration Of Conformity
II 2 D Ex h IIIC T135°C Db ________________________ Year and place of issue, 2020 Adam Dickinson, Leamington Spa, England Managing Director ________________________________________________________________________________________________________ Registered Office: Trelawny SPT Ltd, Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom DOCUMENT No. Q:57/8 www.trelawny.co.uk... - Page 4 73/23/EC DIREKTIVA O STROJIH Z NIZKO VOLTAŽO (nanaša se samo na proizvode na električni pogon) MEGFELELŐSÉGI NYILATKOZAT UYGUNLUK BEYANI Mi. A "Trelawny SPT Limited" cég Trelawny SPT Limited Felelösségünk tudatában kijelentjük, hogy mint a termék szállitója/gyartója AÞaöýdaki, üretim ve tedarikinden tek baÞýna sorumlu olduöu ürünün Termék neve...
- Page 5 DECLARATION OF CONFORMITY Appendix 1 - Hazardous Area Certification The VL303Ex Chisel Scalers are certified compliant to the ATEX Directive (2014/34/EU) for safe use within a hazardous area and has been assessed so by Element Materials Technology. This product conforms to the Standards:...
-
Page 6: Foreword
VL303EX Chisel Scaler FOREWORD Thank you for your purchase of the VL303EX Chisel Scaler. VL303EX Chisel Scaler, please do not hesitate to contact your This manual contains the necessary maintenance information local Trelawny dealer or agent. We always welcome feedback for you to ensure proper operation and care for this machine. -
Page 7: Risk Of Hand Arm Vibration
6.2bar (90psi). STARTING WORK Please note we recommend using a lanyard or strap attached Handled correctly the VL303Ex Chisel Scaler will work quickly and efficiently. Excessive operator pressure will not improve to the optional Drop Protection fall arrestor (39). This should... -
Page 8: Maintenance
VL303EX Chisel Scaler MAINTENANCE Maintenance must only be carried out by a competent Cylinder Ball Valve replacement person, in a suitably equipped workshop. This is a consumable item and will require replacing after Disconnect the tool from the air supply before carrying out approximately 120 -160 hours use;... -
Page 9: Assembly
Intermediate Tube over the DISPOSAL VERY IMPORTANT Dismantle into component form, segregate according to Only Trelawny Aluminium Bronze Chisel must be used in material composition and dispose of using waste recycling this tool. processes specified by local regulations. -
Page 10: Exploded
VL303EX Chisel Scaler EXPLODED DIAGRAM PAGE 10... -
Page 11: Parts List
Chisel 1/2” Sq Shank Spark Resistant 2” Blade 512.3003 VL303 Drop Protection Kit Includes (40,41): 415:3003 Anti Static Lanyard 720.3003 VL303 Arrester Clamp Assembly 819.2375 Connector 1/4” BSPT-3/8” Stem 843.0825 1/4’’ BSP to NPT Connector 446.3303X Service Kit (2,3,4,7,8,13,14,17,18,19,25,28,32) www.trelawny.co.uk... -
Page 12: Technical Specification
© Copyright 2015, Trelawny SPT Limited, CV31 1XT. UK All rights reserved. Any unauthorised use or copying of the contents or part thereof is prohibited. This applies to trademarks, model denominations, part numbers and drawings. Use only genuine Trelawny spares. - Page 13 www.trelawny.co.uk...
- Page 14 VL303EX Chisel Scaler notes PAGE 14...
- Page 15 www.trelawny.co.uk...
- Page 16 DEALER STAMP: need to contact us? Manual Part Number: Trelawny SPT Limited 735.3607 Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom Telephone: +44 (0)1926 883781 Fax: +44 (0)1926 450352 Email: sales@trelawny.co.uk Website: www.trelawny.co.uk...
