Summary of Contents for Major Manufacturing ADAMS RITE 4502 Series
Page 1
1825 VIA BURTON ANAHEIM CA 92806 714-772-5202 / FAX 714-772-2302 EMAIL: MAIL@MAJORMFG.COM WEB: WWW.MAJORMFG.COM INSTRUCTIONS FOR HIT-40AR3 ADAMS RITE 4502/4902 SERIES LIP STRIKE TEMPLATE WHEN USING POWER TOOLS ALWAYS WEAR EYE AND EAR PROTECTION!! Copyright 2007—Major Manufacturing...
MAKE CERTAIN THAT YOU ARE USING THE CORRECT TEMPLATE FOR THE HARDWARE BEING INSTALLED AND YOUR ROUTER HAS A 3/8” OUTSIDE TEMPLATE GUIDE INSTALLED IN THE BASE. GENERAL SAFETY RULES ALWAYS WEAR EYE AND EAR PROTECTION!! Before attempting any installation know how to safely use the power tools involved and how they work.
Page 3
See our catalog or web site for a list of available router template guides. Install a 1/4” diameter aluminum router bit into the router collet and secure tightly. Adjust the router bit so it will route about 1/4” to 3/8” into the door channel. Copyright 2007—Major Manufacturing Page 3...
Page 4
4” wide offset hung door. The center line is 7/8” from the stop, or one half the thickness of the door. Use a combination square and draw a vertical line at this point. Copyright 2007—Major Manufacturing Page 4...
Page 5
Make sure the template is square to the jamb prior to running the second screw in. Template mounted and ready to go. Copyright 2007—Major Manufacturing Page 5...
Page 6
LPS Company. You can find this product at industrial hardware stores or machine shop supplies. This is also a handy product to use for other drilling or tapping chores. Place the router bit in the center of the starting hole. Copyright 2007—Major Manufacturing Page 6...
Page 7
Adjust the depth of the router to cut the thickness of the jamb material only, this should be a cut depth of only about 1/8 inch. Use the router to nibble away this area. Copyright 2007—Major Manufacturing Page 7...
Page 8
Drill out the holes left by the tek screws to 3/16”. These holes will be used to mount the factory mounting bracket. Counter sink both holes for the 10-32 flat head mounting screws supplied by the factory. Copyright 2007—Major Manufacturing Page 8...
Page 9
Finished installation showing strike and dust box. That’s all there is to it!! Copyright 2007—Major Manufacturing Visit our web site at www.majormfg.com for more information or router recommendations, template guides and other templates to make your installations easier and faster.
