Fitting Guidelines.
Unfold these guidelines and read all front and rear pages.
To be left with the customer after installation.
Fitting guidelines for the following models:
CALVIA, PEDROSA
Index.
Front cover.
Fitting guidelines. Page 1 to 8.
Front cover.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CALVIA and is the answer not in the manual?

Questions and answers

Related Manuals for Newman CALVIA

Summary of Contents for Newman CALVIA

  • Page 1 Fitting Guidelines. Unfold these guidelines and read all front and rear pages. To be left with the customer after installation. Fitting guidelines for the following models: CALVIA, PEDROSA Index. Front cover. Fitting guidelines. Page 1 to 8. Front cover.
  • Page 2 FITTING GUIDELINES FOR MODEL: CALVIA & PEDROSA. (These guidelines consist of 8 pages). Important. • Please read all of these guidelines and diagrams before commencing any installation. • This fireplace must be installed by an experienced, suitably qualified, and competent fitter.
  • Page 3 • Never use adhesive alone to fit the fireplace • Brackets, anchorage points and dowels to be fitted against brickwork not plaster. • All mechanical fixings to be chased into mounting wall brickwork to enable complete contact of all rear edges of fireplace to wall so a total bond can be made when also adhering fireplace to wall.

  • Page 4: Fitting Guidelines

    Chimney Type. • Class 1. The chimney and flue must be in accordance with building regulations and any rules in force, with a suitable builders opening and flue, for your chosen fireplace and gas or solid fuel, or electric fire combination.
  • Page 5 4) Correctly prepare the chimney builders opening and install a suitable throat lintel into correct position. 5) Bed hearth level completely using white dry lining wall adhesive or alternatively with 1 part white cement and 5 parts silver sand. Do not use any coloured cement or sand or any other coloured products as this will discolour the stone. 6) Position the legs and adjust position so they will be in correct position with the top header and shelf when eventually fitted, do not fit at this stage.
  • Page 6 (It is advised that when the fireplace has totally dried, to seal all visible surfaces with a suitable stone sealer and let fully dry before carrying out the plaster process). COPYRIGHT. NEWMAN FIREPLACES LTD.

This manual is also suitable for:

Pedrosa
