Contents
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Indicators and Controls. . . . . . . . . . . . . . . . . . . . . .8
Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Amplifier
Installation
&
Operation
Manual
Introduction
Thank you for purchasing a Jensen amplifier. PS series amplifiers offer extreme value and performance. Proper
installation is essential for optimal performance and long-term reliability. Please read through this manual to
familiarize yourself with your amplifier and its functions.
Warranty Service
If your Jensen amplifier should ever require service, you will need to have the original dated receipt. If you need to
return the unit for any reason, always include the receipt with the product.
Installation Assistance
For installation assistance, call 1-800-323-4815 during normal business hours, or visit www.jensen.com at any time.
Features
12dB/octave Butterworth alignment
40Hz – 200Hz crossover frequency range
iX² Bass with continuously variable 0dB to +18dB bass boost centered at 45Hz
Input level control with a 300mV to 8V input range
High level inputs for interfacing with OEM/factory head units
Full range pre-amp output for installation flexibility
Dual status LED diagnostic indicator
Thermal, short circuit and low impedance protection circuitry
Unregulated Pulse Width Modulated (PWM) power supply for extended dynamic range
Balanced driver circuitry and complementary output stage design for low distortion and unparalleled stability
High current output stage easily drives 2 ohm loads
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS1150M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Audiovox PS1150M

  • Page 1 PS1150M Audiovox Electronics Corporation 150 Marcus Boulevard Hauppauge, NY 11788 1-800-323-4815 www.jensen.com ©2005 Audiovox v.121704 Contents Introduction.......1 Features .
  • Page 2: Table Of Contents

    PS1150M Manual de Instalación y Operación Contenido Introducción ..............2 Características .
  • Page 3 PS1150M Installation This device is a high-power audio amplifier intended for installation in vehicles with a 12-Volt negative ground electrical system. Attempting to connect or operate the amplifier in another type of electrical system may cause damage to the amplifier or the electrical system.
  • Page 4: Instalación

    La conexion apropié des cables c' est ilustrée dans le diagramme du câblage. Si les conexions des câbles se font incorrectement l'unité n'opérera pas de façon appropiée et peut s'abîmer d'une manière permanente. Vous suivrez les instructions soigneusement ou vous permetez que l'instalation la réalise un technique qualifié. PS1150M...
  • Page 5: Power Wiring

    PS1150M Wiring Power Wiring Power Terminal (+12V) Connect directly to the vehicle battery positive (+) terminal with a minimum of 10-gauge wire. Remote Terminal (REM) Connect the power antenna or amplifier turn-on lead from the receiver to the amplifier remote terminal.
  • Page 6 Connect the speaker outputs from the receiver to the high level input connector. NOTE: Connect either the low (RCA) OR high-level input – DO NOT connect both at the same time. 4 ohm nominal PS1150M Input Wiring Cableado de Entrada Câblage d’Entrée...
  • Page 7: Cableado

    PS1150M Cableado Alimentación Terminal Eléctrica (+12V) Conecte directamente a el terminal positivo (+) de la batería del vehículo de calibre 10 como mínimo. Terminal Remota (REM) Conectar la antena o la cabeza de encendido del amplificador desde el receptor a la terminal remota del amplificador.
  • Page 8: Indicators And Controls

    Indicateurs et Contrôles Level Filtro del Paso Bajo Nivel de entrada Filtre de Bas Passage Niveau Power Indicator Indicador de energía Indicateur de puissance Bass Boost Bajos PS1150M Low-Pass Filter Protect Indicator Indicador de la protección Indicateur de la protection...
  • Page 9: Indicadores Y Controles

    PS1150M Indicadores y Controles Indicador de energía Proporciona una indicación visual de que el amplificador está encendido. Nivel de Entrada El control de nivel de entrada iguala la salida de su radio con la entrada del amplificador. Después que la instalación se complete, asegúrese de que el control de nivel de entrada en el amplificador esté...
  • Page 10: Troubleshooting

    Specifications subject to change without notice. 12-Month Limited Warranty AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.
  • Page 11: Localización De Problemas

    Las especificaciones están sujetas a cambio sin previo aviso. Garantia Limitade de 12 Meses AUDIOVOX CORPORATION (la Compañía) garantiza al comprador minorista original del presente producto que en el caso de que este producto o cualquiera de las partes del mismo, bajo circunstancias y condiciones de uso normal, tuviera algún defecto, tanto en el material como en la mano de obra, dentro de un plazo de 12 meses a partir de la...
  • Page 12: Localisations De Problèmes

    Garantie Limitée de 12 Mois AUDIOVOX CORPORATION (la Société) garantit à l’acheteur initial du produit que si tout ou partie de ce produit, en cours d’utilisation et sous des conditions normales, venait à présenter des vices de matière primitive ou des défauts de fabrication, dans les 12 mois suivant la date d’achat initial, ce(s) défaut(s) sera(seront) réparé(s) ou remplacé(s)
  • Page 13 PS1150M Audio Precision 0.05 0.02 0.006 Sweep Power output - Rated power @ 2-ohm load. Mono. 75Hz tone. Audio Precision 0.05 0.02 0.006 Sweep Power output - Rated power @ 4-ohm load. Mono. 75Hz tone. THD+N vs. Power Trace Color...
