USB Turntable to MP3 converter
Quick Start Guide
Thanks for purchasing ezcap610 USB Turntable to MP3 converter. The following guides you how
to set up on your computer. Hope this device will bring you nice digital experience.
With this ezcap610 USB Turntable to MP3 converter, you can easily transfer your vinyl record to
MP3 format, so can play on iTunes, or mobile phones, etc.
Features:
1. PLATTER – Place your record here.
2. TONEARM – Comes with a ready to use
pre-balanced tone arm and cartridge.
3. 45 Rpm holder – For 7 inch 45 Rpm LP with big hole
4. On/Off and volume controller.
5. 33/45 switch
6. AA/DC switch – switch power
supply between AA battery and DC
7 LINE OUT
8. MINI USB – For power supply with 5V DC adapter
10. Battery compartment – 4 * AA batteries
11. 45 Rpm adjuster
12. 33 Rpm adjuster
Advertisement
Related Manuals for EzCAP ezcap610
Summary of Contents for EzCAP ezcap610
- Page 1 Hope this device will bring you nice digital experience. With this ezcap610 USB Turntable to MP3 converter, you can easily transfer your vinyl record to MP3 format, so can play on iTunes, or mobile phones, etc.
- Page 2 Note: The adjusters only for adjust when you think the speed is too fast or slow. 13. Speaker How to play your recorders: 1. Undo and lower arm clip. 2. Raise the tone arm, then move it to the side. 3.
- Page 3 Audacity Software Installation Please insert the Software CD into the CD drive, and read it. Double click “Audacity 2.0.3 for Win.exe” file, and select the language you wanted, then click “OK” to start installation. Click “NEXT” and / or select the installation folder to go forward. Please wait for installation finished, and click “Finish”...
- Page 4 Now, you need to set software for capturing and editing audio. Audacity Software Guide Double click “Audacity” icon on your desktop. Please click “Edit” key on the software panel, and select “Preferences”. Please set recording device to be “USB Audio Device”, and channels to “2(Stereo)”. And select “Software...
- Page 5 Play through (Play new track while recording it)”. Now, you can start to record analog audio to be digital MP3 format file. Begin playing your vinyl or cassette and click red record key (see below) to start recording audio - when you want to finish, click the yellow stop key.
- Page 6 Click “File”, and select “Export”, you will get one window. Please write the name of the recording file, and select the “Format” to be MP3 or other format that you wanted. Then select “Save”. You may be asked to provide some additional information about your recording files. Then you can get the recording audio file into the format that you want.
- Page 7 The hardware device doesn’t need any driver. Mac X OS will install the driver automatically. Please check hardware installing correctly. Please go to “Apple logo” \ “About this Mac” \ “More information” \ “Hardware” \”USB”. If the driver has been installed correctly, you should see the “USB Audio Device” or “USB PnP Audio Device”. Audacity Software Installation Note: Please copy the “For Mac”...
- Page 8 Please wait for installation finished, and click “Close” to complete the installation. Now, you need to set software for capturing and editing audio. Audacity Software Guide Please click “Go” and select “Application”, then you will get the window as below.
- Page 9 Open “Audacity” folder and double click “Audacity” icon to start the software. Please click “Edit” key on the software panel, and select “Preferences”. Please click “Audacity” logo on the software panel, and select “Preferences”. Please select recording device to be “USB Audio Device” or “USB PnP Audio Device”, and channels to be “2(Stereo)”.
- Page 10 Now, we start to record analogue audio to be digital MP3 format file. Please click red record key to start recording audio that you wanted. And please click yellow stop key when you want to finish. At first time, we need to do more steps if we want to export as MP3 file. Click “File”, and select “Export”.
- Page 11 Maybe you need to give some information, such as file name and location. And you need to select file format to MP3 format, then click “Save”. You may be asked to provide some additional information about your recording files. Then you can get the recording audio file into the format that you want.
- Page 12 Now, you can get MP3 file through your analog audio device. You can use the file for your iPod by iTunes. Note: Please go to the link - http://manual.audacityteam.org/o/ to get the more information for Audacity software functions.
