- Page 1 USER MANUAL Simulated Sinewave Inverter/Charger V. 2.1...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction ............................. 1 2. Important Safety Warning (SAVE THESE INSTRUCTIONS) ..............1 3. Product Overview ........................... 2 4. Installation ............................... 2 5. Operation..............................3 6. Trouble Shooting ............................ 8 7. Specifications ............................8... -
Page 3: Introduction
1. Introduction Thank you for purchasing this power inverter. This simple power inverter is designed to power your home appliances or precious 3C electronics. It also can handle motor-type loads with high surge power such as vacuums, small freezers, or drills. With built-in AC charger, it can convert utility power to battery power and provide continuous power to connected equipment during power failure. -
Page 4: Product Overview
3. Product Overview Power switch Status indicator Charging indicator Fault indicator Function buttons (Please see the Operation section for the details) LCD display AC input AC output socket Input circuit breaker 10. External battery connectors 11. DC fuse 4. Installation NOTE: Before installation, please inspect the unit. -
Page 5: Operation
Fig 3 3) Multiple batteries in parallel connection(Refer to Fig. 4): Each battery's voltage must be equal to the Nominal DC Voltage of the unit. Fig 4 Step 4- Make sure to connect the polarity of battery side and the unit correctly. Positive pole (Red) of battery to the positive terminal (+) of the unit. - Page 6 Audible Alarms Buzzer Audible Alarm Messages Inverter Mode (Low-battery Voltage) Buzzing every 1 seconds 110% overload warning Buzzing every 0.5 second Overcharge Buzzing continuously Fault mode Buzzing continuously LCD Display Display Function Input source information Indicates the AC input Indicates input voltage, input frequency, PV voltage, charging current, battery voltage, Configuration Program and Fault Information Indicates the setting programs.
- Page 7 Mode operation information Indicates unit connects to the mains. Indicates load is supplied by utility power. Indicates the utility charger circuit is working. Indicates the DC/AC inverter circuit is working. LCD Setting After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “SCROLL” button to select setting programs.
- Page 8 If self-defined is selected in program 02, this program can be set up. Setting range is from 13.0V to 14.6V for 12Vdc model and increment of each click is 0.1V. Setting range is from 26.0V to 29.2V for 24Vdc model and increment of each click is 0.2V.
- Page 9 Operating Mode Description Operation mode Description LCD display Standby mode Charging by utility. Utility input bypass to Note: output, charger is *Standby mode: The inverter is available and LCD not turned on yet but at this backlight is off time, the inverter can charge battery with AC bypass output.
-
Page 10: Trouble Shooting
6. Trouble Shooting Use the table below to solve minor problems. Problem LCD/LED/Buzzer Explanation / Possible cause What to do Charge the unit at least 8 Battery voltage is too low. When power fails, hours. Battery low alarm the backup time is Battery capacity is not full even Check the date code of the issue quickly.
