- Page 1 QUALITY, RELIABILITY, & PURE BLISS MATCHED COMPONENT SPEAKER SYSTEM ABC680V ABC600V ABC525V OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTURE USE AND REFERENCE...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
-
Page 3: Table Of Contents
Other information can be located by using the table of contents. We at Audiobahn Inc. have worked very hard to make sure that all of the information in this manual is current, but, as we are costantly finding new ways to improve our product, this information is subject to change without notice. -
Page 4: Introduction
Installer Training Programs. Please read your warranty, keep your receipt, and original carton for possible future use. To get a free brochure on Audiobahn products in the US call (714) 988-0400 or e-mail us at sales@audiobahn.com. Continuous exposure to sound pressure levels over 100dB may cause permanent hearing loss. -
Page 5: Features And Specifications
320 ACH POWER ABC600V: 140 RMS POWER 280 ACH POWER ABC525V120 RMS POWER 240 ACH POWER FREQUENCY ABC680V: 25Hz - 25kHz ABC600V: 30Hz - 25kHz ABC525V: 35Hz - 25kHz MAGNET WEIGHT ABC680V: 15oz ABC600V: 15oz. ABC525V: 15oz. SENSITIVITY ABC680V: 93dB ABC600V: 91dB ABC525V: 90dB �... - Page 6 Mounting Amplifier Midwoofer Tweeter Tweeter Amplifier / Source �...
- Page 7 Wiring and Controls From left to right you have three sets of terminals. The left terminal in each set is negative (-) and the right terminal is positive (+). (1) is the input terminals. This is the speaker wire coming from your amplifier or source unit. (2) is the tweeter output. This is the speaker wire going to the tweeter.
-
Page 8: Choosing A Location
Audiobahn AS series speakers are designed to fit into almost any factory location. Again, if at all possible it is recommended that you use a factory location. This applies mostly to later model vehicles. For those earlier models that do not have factory locations or are limited to front locations, it is recommended that you choose an are with sufficient airspace. -
Page 9: Installation
Installation Note: Audiobahn Strongly recommends that you operate your system at low volumes prior to the completed installation of your Audiobahn speakers. This will allow a test of the speaker before securing it to its permanent location. Caution: Make sure that all speaker wiring is fully protected from cuts, tears and possible wear. All short circuits developing as a result could severely damage the source unit or possibly the amplifier as well as the speakers themselves. -
Page 10: Wiring
Wiring Wiring Audiobahn recommends using at least 18-gauge wire with your new speaker system. Thinner gauge wire may easily be severed and can cause damage to your system should any bare wires come in contact with the vehicles chassis. Makes sure that your audio system is off while installing and connecting your new Audiobahn Speakers. -
Page 11: Securing The Speaker
Securing the Speaker Once you have tested your system and confirmed that it is operating properly, turn off your system and prepare for the final mounting of the speakers. 1) Position the speaker into the mounting hole and confirm the correct mounting location and hole placement. -
Page 12: Troubleshooting
Troubleshooting In the event that your Audiobahn speakers appear to require service we ask that you first do a little trouble shooting to determine if the problem is actually the speaker, or a problem located in a different part of the vehicle such as the amplifier, wiring, fusing or possibly the source unit. -
Page 13: Warning And Disclaimer
Using a fuse of a different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change with out notice. For the most updated Specifications call Audiobahn, your local Authorized Audiobahn Dealer, or check the Audiobahn web site. www.audiobahn.com... -
Page 14: Warranty
Audiobahn products are manufactured with the highest quality components and some of the most advanced technology available. Because of this, we recommend that you have your new products installed by an Authorized Audiobahn Dealer. (A list of Authorized Audiobahn Dealers can be found on our web page).
