ZigBee™
command of door lock
ZLOCK
User Manual
Revision: 1.0
Document: UM_ZLOCK_20110919_001_01_00.doc
S.A. au capital de 167 200 €
R.C.S. Saint Brieuc TGI 450 570 767
Siège social : 8 rue Bourseul 22300 Lannion France
Tél. : +33 (0) 2 96 48 68 18 – Fax : +33 (0) 2 96 48 19 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZigBee ZLOCK and is the answer not in the manual?

Questions and answers

Related Manuals for Cleode ZigBee ZLOCK

Summary of Contents for Cleode ZigBee ZLOCK

  • Page 1 ZigBee™ command of door lock ZLOCK User Manual Revision: 1.0 Document: UM_ZLOCK_20110919_001_01_00.doc S.A. au capital de 167 200 € R.C.S. Saint Brieuc TGI 450 570 767 Siège social : 8 rue Bourseul 22300 Lannion France Tél. : +33 (0) 2 96 48 68 18 – Fax : +33 (0) 2 96 48 19 11...

  • Page 2: Warranty

    In order to invoke the warranty, the buyer must immediately send written notice to CLEODE of the flaws that it attributes to the device. It must enable CLEODE to have access to the device to observe these defects and repair them. The warranty provided by CLEODE is strictly limited to the equipment provided and shall only have for effect the replacement or repair, at CLEODE’s expense, on its own premises, of all devices or parts that are not...

  • Page 3: Table Of Contents

    OUBLE SIDED TAPE INSTALLATION III.1.2 ........................10 ACCORDEMENT III.2 ZLOCK ......................12 TARTING UP III.3 .................. 12 ESTART OF THE ASSOCIATION PHASE III.4 ............................13 ESET TECHNICAL FEATURES......................14 REPAIR AND MAINTENANCE ...................... 15 UM_ZLOCK_20110919_001_01_00 CLEODE Page 3 sur 16...

  • Page 4: Table Of Revisions

    ZigBee command of door lock – User Manual ABLE OF REVISIONS Version Authors(s) Version description Date CLEODE Initial version 15/09/2011 CLEODE Validated document 22/09/2011 UM_ZLOCK_20110919_001_01_00 CLEODE Page 4 sur 16...

  • Page 5: Reference Documents

    ZigBee command of door lock – User Manual EFERENCE DOCUMENTS N° Document Description ZigBee_Cluster_Library_Public Spécification de la Zigbee Cluster Library ZigBee_Home_Automation_Profile Spécification du profile Home Automation ZigBee_Specification Spécification de la norme ZigBee UM_ZLOCK_20110919_001_01_00 CLEODE Page 5 sur 16...

  • Page 6: Iintroduction

    OPYRIGHT The CLEODE trademark and the CLEODE logo are properties of CLEODE SA, France. This document also refers to trademarks and other product names that are registered trademarks of their respective owners. Copyright © 2009 CLEODE SA. All rights reserved.

  • Page 7: Zlock Description

    This application is a part of the profile Home Automation. II.2.1 OOR LOCK APPLICATION DESCRIPTION Device ID : Door Lock Endpoint number: 1 Clusters : Server Client Basic (0x0000) Identify (0x0003) Groups (0x0004) Scenes (0x0005) Door Lock (0x0101) UM_ZLOCK_20110919_001_01_00 CLEODE Page 7 sur 16...

  • Page 8: Ii.2.2 Clusters Description

    IdentifyTime attribute value, the user asks the device to blink the light, during a number of seconds specified by this value. Attribute Attribute ID IdentifyTime 0x0000 Cluster Groups: This cluster allows storing the name of the groups to which the ZLOCK belongs. Attribute Attribute ID NameSupport 0x0000 UM_ZLOCK_20110919_001_01_00 CLEODE Page 8 sur 16...
  • Page 9 The attribute Lock State allows knowing if the striking plate is locked or not. The attribute Lock Type allows to know the type of used door lock, in the case of the ZLOCK it costs 0x00 (DEAD BOLT). UM_ZLOCK_20110919_001_01_00 CLEODE Page 9 sur 16...

  • Page 10: Installation And Network Association

    To connect the ZLOCK, follow the procedure this below. Connect the supply of the ZLOCK as indicated below. Attention: Shut down the power supply before any intervention and it till the end the manipulations. UM_ZLOCK_20110919_001_01_00 CLEODE Page 10 sur 16...
  • Page 11 ZigBee command of door lock – User Manual Connect the door lock on the ZLOCK. Attention: a single door lock must be connected by ZLOCK. UM_ZLOCK_20110919_001_01_00 CLEODE Page 11 sur 16...

  • Page 12: Iii.2 Starting Up Zlock

    ESTART OF THE ASSOCIATION PHASE If the ZLOCK is not associated, the user can ask him at any time to join a network. For this, the user has to press during 3 seconds on the button. UM_ZLOCK_20110919_001_01_00 CLEODE Page 12 sur 16...

  • Page 13: Iii.4 Reset

    ESET If need, the user can reset of the ZLOCK . For this, he has to press on the button during 5 seconds. When the ZLOCK reset, the LED flashes twice and turn off. UM_ZLOCK_20110919_001_01_00 CLEODE Page 13 sur 16...

  • Page 14: Technical Features

    100 g Power supply Max. 24V Commutation Max. 3A Measurement 54 x 52 x 32 mm Transmission range 100 m outdoor 30 m indoor Managed channels (frequency) 16 ZigBee™ channels (2.405 to 2.480 GHz) UM_ZLOCK_20110919_001_01_00 CLEODE Page 14 sur 16...

  • Page 15: Repair And Maintenance

    ZigBee command of door lock – User Manual EPAIR AND MAINTENANCE Defective equipments shall be first reported to the CLEODE support team in order to be assigned an RMA number. Be prepared to state your name, company and the serial number of the defective item to the support personnel.
  • Page 16 ZigBee command of door lock – User Manual CLEODE S.A. Technical Support Division 8, rue Bourseul 22300 Lannion France Phone : +33 (0) 2 96 48 68 18 Fax : +33 (0) 2 96 48 19 11 E-mail : support@cleode.com Web : http://www.cleode.com...
