Summary of Contents for Briggs & Stratton SpeedClean 020261-0
Page 1
SpeedClean™ is a trademark of Briggs & Stratton Power Products. SpeedClean™ es una marca registrada de Briggs & Stratton Power Products. BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC JEFFERSON,WISCONSIN, U.S.A. Model No. 020261-0 (2200 PSI Pressure Washer) Manual No. 198968GS Revision 0 (01/16/2006)
Safety Rules........2-5 Know Your Pressure Washer......6 Assembly.
Page 3
SpeedClean™ 2200 PSI Pressure Washer WHEN ADDING FUEL • Turn pressure washer OFF and let it cool at least 2 minutes before removing gas cap. • Fill fuel tank outdoors. • DO NOT overfill tank. Allow space for fuel expansion.
Page 4
• Always wear safety goggles when using this equipment or in vicinity of where equipment is in use. • Before starting the pressure washer, be sure you are wearing adequate safety goggles. Unintentional sparking can result in fire or electric shock.
Page 5
• DO NOT by–pass any safety device on this machine. • Before starting pressure washer in cold weather, check all parts of the equipment to be sure ice has not formed there. • NEVER move machine by pulling on hoses. Use handle provided on unit.
KNOW YOUR PRESSURE WASHER Read this Operator’s Manual and safety rules before operating your pressure washer. Compare the illustrations with your pressure washer to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference.
WASHER FOR USE If you have any problems with the assembly of your pressure washer or if parts are missing or damaged, call the pressure washer helpline at 1-800-743-4115. If calling for assistance, please have the model, revision, and serial number from the data tag available.
Figure 5 — Attach Detergent Siphon Hose to Pump Add Engine Oil and Fuel • Place pressure washer on a level surface. Any attempt to crank or start the engine before it has been properly filled with the recommended oil will result in equipment failure.
• Always wear safety goggles when using this equipment or in vicinity of where equipment is in use. • Before starting the pressure washer, be sure you are wearing adequate safety goggles. Checklist Before Starting Engine Review the unit’s assembly to ensure you have performed all of the following.
How to Start Your Pressure Washer To start your pressure washer for the first time, follow these instructions step-by-step.This starting information also applies if you have let the pressure washer sit idle for at least a day. Make sure unit is in a level position.
When starting engine, position yourself as recommended in Figure 12 and start engine according to instructions given in engine operator’s manual.Also see operating instructions tag located on the pressure washer. Figure 12 - Recommended Starting Position WARNING Rapid retraction of starter cord (kickback) will pull hand and arm toward engine faster than you can let go.
How to Use the Adjustable Nozzle You should now know how to START and STOP your pressure washer.The information in this section will tell you how to adjust the spray pattern and to apply detergent or other cleaning chemicals. CAUTION A pressure washer produces a high pressure spray which increases risk of injury and damage to unit.
• Operate this unit on a stable surface. • Be extremely careful if you must use the pressure washer from a ladder, scaffolding or any other relatively unstable location. • Firmly grasp spray gun with both hands when using high pressure spray to avoid injury when gun kicks back.
Shipping Weight ......54 lbs. GENERAL MAINTENANCE RECOMMENDATIONS The pressure washer warranty does not cover items that have been subjected to operator abuse or negligence.To receive full value from the warranty, the operator must maintain the pressure washer as instructed in this manual.
Purchase an O–Ring/Maintenance Kit, part number 191922GS by contacting the nearest authorized service center. It is not included with the pressure washer.This kit includes replacement o-rings, rubber washer and water inlet filter. Refer to the instruction sheet provided in the kit to service your unit’s o-rings.
Contact the nearest authorized service center to purchase PumpSaver. To use PumpSaver, make sure the pressure washer is turned off and disconnected from supply water. Read and follow all instructions and warnings given on the PumpSaver container.
Detergent fails to mix with spray. Engine runs good at no-load but "bogs" when load is added. Pressure washer stops during operation. SpeedClean™ 2200 PSI Pressure Washer Cause Nozzle in low pressure mode. Water inlet is blocked. Inadequate water supply.
Effective December 1, 2005 replaces all undated Warranties and all Warranties dated before December 1, 2005 Briggs & Stratton Power Products Group, LLC will repair or replace, free of charge, any part(s) of the pressure washer that is defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser.
CONSERVE ESTAS INSTRUCCIONES TABLA DE CONTENIDOS Reglas De Seguridad ....... . 20-23 Conozca Su Lavadora de Presión .
Page 21
Lavadora de Presión 2200 PSI de SpeedClean™ ADVERTENCIA Al motor funcionar, se produce monóxido de carbono, un gas inodoro y venenoso. El respirar el monóxido de carbono, producirá náusea, desmayo o la muerte. Algunas sustancias químicas o los detergentes pueden ser perjudiciales si inhalados o ingeridos, causando la náusea severa, desmayando o para envenenar.
Page 22
ADVERTENCIA El rápido repliegue del cable del arrancador (retroceso) impedirá que el usuario suelte el cable a tiempo y tirará de su mano y brazo hacia el motor. Como resultado, podrían producirse fracturas, contusiones o esguinces. • Antes de arrancar el motor, apunte SIEMPRE con la pistola rociadora hacia una dirección segura y apriete el gatillo para descargar la presión y evitar el retroceso.
Page 23
Lavadora de Presión 2200 PSI de SpeedClean™ PRECAUCIÓN Hacer funcionar el motor a velocidades excesivas aumenta el riesgo de lesiones personales. • NO juegue con partes que puedan aumentar o disminuir la velocidad de mando. • NO opere la máquina lavadora a presión con un valor de presión superior a su clasificación de presión.
Page 24
CONOZCA SU MAQUINA LAVADORA A PRESION Lea el manual del operario y las reglas de seguridad antes de poner en marcha su máquina lavadora a presión. Compare las ilustraciones con su máquina lavadora a presión para familiarizarse con las ubicaciones de los diferentes controles y ajustes.
Lavadora de Presión 2200 PSI de SpeedClean™ MONTAJE IMPORTANTE: Lea totalmente el manual del operario antes que intente ensamblar u operar su lavadora a presión. Desembale la Lavadora a Presión Saque todo el contenido de la caja de cartón, a excepción de la lavadora a presión.
Inserte el perno del soporte a través de los orificios desde fuera de la unidad y sujete una perilla de plástico desde el interior de la misma unidad.Apriete manualmente (Figura 23). Figura 23 - Sujetar el Manubrio Coloque la limpiar el tanque sobre los orificios del manubrio (vista desde la parte delantera de la unidad).
Lavadora de Presión 2200 PSI de SpeedClean™ Conecte la Manguera y el Suministro de Agua a la Bomba IMPORTANTE: Usted deberá armar la extensión para boquillas y conectar todas las mangueras antes de darle arranque al motor. La bomba resultará dañada si arranca el motor sin tener todas las mangueras conectadas y el suministro agua abierto.
Page 28
CÓMO USAR SU MÁQUINA LAVADORA A PRESIÓN Si tiene problemas operando su máquina lavadora a presión, por favor llame a la línea de ayuda para máquinas lavadoras a presión al 1-800-743-4115. Ubicación del Lavadora a Presión Espacio Libre Alrededor del Lavadora a Presión ADVERTENCIA Los gases y el calor de escape pueden inflamar los materiales combustibles y las estructuras o dañar el...
Page 29
Lavadora de Presión 2200 PSI de SpeedClean™ Cuando arranque el motor, colóquese en la posición recomendada en la Figura 33 y siga las instrucciones del manual del operario del motor. Consulte también la etiqueta de instrucciones situada en la limpiadora a presión. Figura 33 - Posición Recomendada para el Arranque ADVERTENCIA El rápido repliegue del cable del arrancador...
Cómo Usar la Boquilla Ajustable Usted ya debe saber como darle ARRANQUE a su máquina lavadora a presión y como DETENERLA. La información de esta sección le dirá como ajustar el patrón de rociado y como aplicar detergente u otros químicos de limpieza. PRECAUCIÓN El lavadora de presión produce un rocío alto de la presión cuál riesgo de aumentos de la herida y dañe a la unidad.
Lavadora de Presión 2200 PSI de SpeedClean™ Aplicación del Detergente Usando la Boquilla Ajustable IMPORTANTE: Utilice detergentes diseñados específicamente para máquinas lavadoras a presión. Los detergentes caseros podrían dañar la bomba. PRECAUCIÓN Usted deberá conectar todas las mangueras antes de darle arranque al motor.
Lavadora de Presión 2200 PSI de SpeedClean™ Coloque el anillo 'o' en la ranura respectiva. Empuje el anillo 'o' hasta que quede ajustado contra el colador del filtro en línea. Conecte la extensión para boquillas a la pistola de rociado de la manera descrita anteriormente en este manual.
Page 34
PREPARANDO LA UNIDAD PARA SU ALMACENAMIENTO El agua no debe permanecer en la unidad por un largo periodo de tiempo. Los sedimentos o minerales se pueden depositar en las piezas de la bomba y "congelar" la acción de la bomba. Si usted no piensa usar el lavador a presión por mas de 30 días, siga este procedimiento: Vacíe el depósito de limpieza como se indica a continuación: Desconecte la manguera de inyección de detergente...
Lavadora de Presión 2200 PSI de SpeedClean™ REPARACION DE AVERIAS Problema La bomba presenta los siguientes problemas: no produce presión, produce una presión errada, traqueteo, pérdida de presión, bajo volumen de agua. El detergente no se mezcla con el rociado. El motor funciona bien cuando no tiene cargas, pero funciona "mal"...
Page 36
POLÍTICA DE GARANTÍA PARA EL PROPIETARIO DE UNA LAVADORA A PRESIÓN BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC Fecha de entrada en vigor:1 de Diciembre de 2005. Sustituye a todas las garantías sin fecha y a las de fecha anterior al 1 Diciembre de 2005. Briggs &...
