Daewoo Mega 250-V Operation And Maintenance Manua page 59

3. HORN BUTTON (TWO PLACES)
Pressing the left button at the tip of the
pilot control valve lever (joystick) (Figure
51) or the button at the end of the
combination switch (Figure 52) will sound
the horn.
NOTE: Starter switch must be "ON."
4. CIGAR LIGHTER
Push the lighter all the way into the socket
and release your hand. After pushing it in,
it will be ejected when it is heated. If it
does not eject after a short time, pull it out
and have it serviced.
IMPORTANT
The cigar lighter is powered by a 24
volt circuit. Never plug any 12 volt
device into the cigar lighter.
K1000896E Operation and Maintenance Manual
Figure 51
Figure 52
Figure 53
AHO0890L
HAOA780L
Operating Controls 2-27
