2. Release the screw cap (6, Figure 114 and
Figure 116) and unscrew.
3. Release the lock nut (5, Figure 114) and
turn the adjusting
counterclockwise until the brake disk is
free.
4. Install lock nut (5, Figure 114) and screw
cap (6) and tighten both as far as possible.
This will protect
assembly from dirt.
NOTE: Now, the vehicle does not have
any brake function. The vehicle
must
moving
means.
vehicle into operation again, the
brake
according
regulations.
ADJUSTING REGULATIONS
During this adjusting process, the parking brake must be released, i.e. the bank of cup springs (3, Figure
114) must be completely pretensioned.
1. Park vehicle on an even surface and place wheel chocks in front of and behind tires. Only then,
release the parking brake.
2. Release the screw cap (6, Figure 114) and unscrew.
3. Release the lock nut (5, Figure 114) (size 24 or 30) and turn the adjusting screw (4) with socket
wrench (size 8 or 10) clockwise until the two brake pads (1 and 2) make contact with the brake disk.
4. Turn the adjusting screw (4, Figure 114) counterclockwise and set the clearance specified in the
following table.
Type
Small
Large
4-70 Inspection, Maintenance and Adjustment
screw (4)
the parking brake
be secured against
away with proper
Before putting the
has to be adjusted
to adjusting
Adjusting Screw
M 16 (size 8)
M 20 (size 10)
Figure 116
Clearance (mm)
min.
Rated clearance
max
min.
Rated clearance
max
K1000896E Operation and Maintenance Manual
Turns
0.5 mm
1/4
(0.02 in)
1.0 mm
1/2
(0.04 in)
1.5 mm
3/4
(0.06 in)
1.0 mm
2/5
(0.04 in)
2.0 mm
4/5
(0.08 in)
3.0 mm
1 1/5
(0.12 in)
