INSTALLATION GUIDE
UltraSwing​
Congratulations on your UltraSwing! You're only a few steps away from hitting the trail.

WARNING: Never exceed the 250 lbs total weight rating of the UltraSwing. In a severe off-road
application, we recommend reducing the total weight to 150lbs. UltraSwing is tow rated to
10,000 lbs (1,000 lb tongue). Never exceed your vehicle's towing capacity. Subtract the weight
of the UltraSwing (70 lbs), as well as the weight of your spare tire and all other products,
mounted to the UltraSwing to determine your vehicle's tongue weight.
RIGd Supply 1533 W Orangewood Ave, Orange, CA 92868 | info@rigdsupply.com | 714-820-9444

Swing Out Tire Carrier
™​




Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraSwing Swing Out Tire Carrier and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIGd Supply UltraSwing Swing Out Tire Carrier

Summary of Contents for RIGd Supply UltraSwing Swing Out Tire Carrier

  • Page 1 UltraSwing (70 lbs), as well as the weight of your spare tire and all other products,  mounted to the UltraSwing to determine your vehicle’s tongue weight.    RIGd Supply 1533 W Orangewood Ave, Orange, CA 92868 | info@rigdsupply.com | 714-820-9444   ...
  • Page 2     Installing the RIGd UltraSwing on your vehicle  1. Grease the sides of the UltraWedge (Figure 1) As well as the top face of the wedge to allow it  to travel while tightening  2. Install UltraSwing into the hitch  3.
  • Page 3     Figure 3     Installing Wheel Plate    For 32-inch or smaller tires or plan to run an  Ultraplate we recommend starting at the  lowest set of holes.     For 33-34-inch tires we recommend to use  the middle set of holes.   ...
  • Page 4   Please note the bolts and washers go on  the back side with nuts facing the tire.    (This will ensure maximum clearance if  installing an UltraPlate)      Compression Latch Adjustment  Washers    Your latch has been pre-adjusted by RIGd.  However, if you’d like to add more ...
  • Page 5   Figure 6   Limited Lifetime Warranty  RIGd Supply offers a Limited Lifetime Warranty on the structure of each UltraSwing to the  original purchaser.  Exclusions  1. UltraSwings that have been abused, crashed, altered, modified, or installed on vehicles  other than those approved by RIGd Supply ...
