RIDGECREST STATIONARY DINING CHAIR ASSEMBLY INSTRUCTIONS
PART LIST
A
B
C
D
E
F
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
SAVE THESE INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
1-866-905-4107 OR WWW.YOTRIOINT.COM
QUANTITY
1 PC
1 PC
1 PC
4+ 1 PC
2 +1 PC
1 PC
DESCRIPTION
LEFT ARM
RIGHT ARM
SEAT
SMALL BOLT AND WASHER
LARGE BOLT AND WASHER
ALLEN WRENCH
Page 1/3
Advertisement
Table of Contents
Related Manuals for YOTRIO RIDGECREST
Summary of Contents for YOTRIO RIDGECREST
- Page 1 SAVE THESE INSTRUCTIONS RIDGECREST STATIONARY DINING CHAIR ASSEMBLY INSTRUCTIONS ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC LEFT ARM 1 PC RIGHT ARM 1 PC SEAT 4+ 1 PC SMALL BOLT AND WASHER 2 +1 PC...
- Page 2 RIDGECREST STATIONARY DINING CHAIR ASSEMBLY INSTRUCTIONS (CONT.) STEP 1 A. PLACE LEFT ARM (A) ON ITS SIDE, ON A FLAT, PROTECTED SURFACE. B. ALIGN SEAT (C) WITH LEFT ARM (A) WITH FRONT OF SEAT FACING STRAIGHT LEGS OF LEFT ARM (A) .
- Page 3 RIDGECREST STATIONARY DINING CHAIR ASSEMBLY INSTRUCTIONS (CONT.) STEP 3 A. ROTATE CHAIR TO THE UPRIGHT POSITION. B. TIGHTEN ALL BOLTS COMPLETELY USING ALLEN WRENCH (F). C. ASSEMBLY IS COMPLETE. ** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH (F) AND PERIODICALLY TIGHTEN ALL BOLTS.
