FSD-C Series
Circular Single Blade
Externally Resettable
Combination Fire and Smoke
and Volume Control Damper
PATENT APPLIED FOR
•
ES classified fire dampers with reduced smoke leakage characteristics to
BS EN 1366-2 (test standard) and BS EN 13501-3 (extended field of application)
•
Aerodynamically Air Control tested to BS EN 1751
•
Tested and assessed installation methods in differing support constructions BS EN 1366-2
•
Integrated volume control capability
•
Can be installed from one side of the fire separation without the need to fit a
secondary installation plate or provide fire-rated infill material
•
Replaceable thermal fuse element from outside of the duct.
•
Commissioning friendly
•
Blade Position Indicator
•
IP54 degree of protection
•
Momentary toggle test switch for periodic damper testing
•
LED green indication when lit indicates that a supply voltage is present and that the
temperature fuses are operational
•
Damper casings conform to BS EN 1506
•
CE marked complying with the requirements of EN 15650
SC Option
VC Option
ESC Option
Advertisement
Related Manuals for BSB FSD-C Series
Summary of Contents for BSB FSD-C Series
- Page 1 FSD-C Series SC Option Circular Single Blade Externally Resettable Combination Fire and Smoke and Volume Control Damper VC Option PATENT APPLIED FOR • ES classified fire dampers with reduced smoke leakage characteristics to BS EN 1366-2 (test standard) and BS EN 13501-3 (extended field of application) •...
- Page 2 What is a fire damper and why might they be needed? positions on the surface structure to which the plate will be affixed, The FSD-C Series Single Blade Circular Fire Damper is designed to allowing for a quick and efficient install.
- Page 3 Should the damper require to be reclosed following exposure to temperatures greater than 400°C, the effectiveness of the seal The BSB FD-C combination fire and volume control damper shall may be reduced. have a tested or assessed installation method that matches the The damper’s single blade construction maximises the free area...
- Page 4 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Product Specification Installation Plate Case The installation plate allows the damper Galvanised mild steel to BS EN 10346 DX 51D Z275 to be fixed into place from one side only 0.6mm thick for 100mm dia.
- Page 5 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Performance and Weights Performance Data Model FSD-C100 Model FSD-C200 Pressure Drop Graph - Pressure Drop Graph - 100mm diameter. 200mm diameter. 67.5° from open 67.5° from open Free area = 64% Free area = 85% 45°...
- Page 6 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Product Dimensions The FSD-C FS Series - Fire/Smoke Damper FSD-C FS Without Installation Plate Note: All dimensions are nominal and may change due to varying coil widths NB: FSD-C FS without installation plate is not CE marked 173.5...
- Page 7 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Product Dimensions The FSD-C SC Series - Control Damper FSD-C SC Without Installation Plate Note: All dimensions are nominal and may change due to varying coil widths NB: FSD-C SC without installation plate is not CE marked 173.5...
- Page 8 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Product Dimensions The FSD-C VC Series - Volume Control Damper FSD-C VC Without Installation Plate Note: All dimensions are nominal and may change due to varying coil widths NB: FSD-CVC Series is not CE marked 173.5...
- Page 9 Actuators should have a clamping facility suitable for the 8mm dia. spindle and an anti-rotation mechanism support system to ensure stability of the fitted actuator.The anti-rotation mechanism should be affixed to the mounting plate only and not directly to the damper body. Please refer to BSB sales office for further information. www.bsb-dampers.co.uk...
- Page 10 The addition of the PMC actuator allows this tested product to become fully automatic in its operation via the fire detection system or one of the BSB control panels.To comply with the forthcoming revision of the fire damper test standard.
- Page 11 The addition of the PMC actuator allows this tested product to become fully automatic in its operation via the fire detection system or one of the BSB control panels.To comply with the forthcoming revision of the fire damper test standard.
- Page 12 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Product Testing FSD-C in Dry Wall - Actuator inside and outside of furnace Tested to BS EN 1366-2 - Test Report No. 279799 refers Test Conclusions: The FSD-C fire/smoke damper satisfied the requirements of BS EN •...
- Page 13 FSD-C Series Single Blade Combination Fire and Smoke Dampers – Product Testing FSD-C in Dry Wall FSD-C in Dry Wall Test Report No. 279799 refers Test Report No. 279799 refers Actuator outside of furnace Actuator inside of furnace GTEC FIREBOARD...
-
Page 14: Installation Method
As a guide, this should take annually. Please refer to BSB Operating and Maintenance instructions. Reference should be made to BS 5588-12 and BS 9999 for more information. -
Page 15: Access Doors
Access Doors for safe access for future damper maintenance, operation and inspection should be a consideration when designing Diameter any H&V system. BSB offer access doors to suit both rectangular and circular ducting and these brochures are available to be viewed and/or downloaded from our web site www.bsb-dampers.co.uk... - Page 16 Backdraught Dampers Single Blade Dampers For full details of the complete BSB Product Range, please refer to our individual product brochures, sales office or website. BSB Engineering Services Limited Unit 56,TrinityTrade Centre, Mill Way, Sittingbourne, Kent ME10 2PD, UK •Tel: +44 (0)1795 422609 • Fax: +44 (0)1795 429543 For purchase orders and order related enquiries, please email: orders@bsb-dampers.co.uk...
