Ø 8mm
+0,5
72mm
- 0
12Vdc set up example
Input cable
IN
OUT
Output cable
Domus Line s.r.l., Via Maestri del Lavoro 1, 33080 Porcia (PN) Italy - tel. +39 0434 /595911 - fax. +39 0434/923345 - info@domusline.com - www.domusline.com
Micro12
distributor
Converter 12Vdc
Micro12
distributor
LED profile 12Vdc
LED spotlight 12Vdc
obstructed by shelves positioned
Min. 10mm
Fig 1
24Vdc set up example
Fig 4
WARNING
detection field must not be
too close of the sensor
Fig 2
Micro24
distributor
adapter
IN
Micro24
OUT
distributor
suggestion max 10cm
Detection area
Area di rilevamento
100cm
Top view
vista dall'alto
160cm
Fig 3
Converter 24Vdc
LED profile 24Vdc
LED spotlight 24Vdc
Fig 5
Cod. 3488700
